Quick Details
-
Pitch:
-
7.50mm
-
Rated Current:
-
16A
-
Rated voltage:
-
250V
-
Screw:
-
M3.0
-
Insulation resistance:
-
5000MΩ/1000V
-
Withstanding voltage:
-
AC2000V/1Min
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
ZH360-750
-
Material:
-
PA66 UL94V-0
-
Pitch:
-
7.50mm
-
Rated Current:
-
16A
-
Rated voltage:
-
250V
-
Screw:
-
M3.0
-
Insulation resistance:
-
5000MΩ/1000V
-
Withstanding voltage:
-
AC2000V/1Min
|
Pitch：7.50MM
|
|
|
|
Part
|
Material
|
Plated
|
|
Frame:
|
PA66 UL94V-0
|
－
|
|
Contact:
|
Brass
|
Tin
|
|
Screw:
|
M3.0Steel
|
Ni
|
|
Wireprotector:
|
Stainless Steel
|
－
|
|
|
|
|
|
Electrical
|
|
|
|
Voltage:
|
250V
|
|
|
Current:
|
16A
|
|
|
Wire size:
|
14-22AWG
|
|
|
Poles:
|
2-30P
|
|
|
Insulation Reslistance:
|
5000MΩ/1000V
|
|
|
Withstand Voltage:
|
AC2000V/1Min
|
|
|
|
|
|
|
Mechanical
|
|
|
|
Acceptable Temperation:
|
-33℃~+120℃
|
|
|
Max Soldering:
|
+250℃,5Sec
|
|
|
Strip Length:
|
5.0-6.0mm
|
|
