Quick Details
-
Application:
-
Outdoor Garden Agriculture Irrigation Deep Well
-
Material:
-
Plastic + Alloy
-
Horsepower:
-
100psi / 7.0 Bar
-
Voltage:
-
12V 24V DC
-
Product name:
-
Solar Water Pump
-
Motor:
-
Permanent Magnet, Thermally Protected
-
Structure:
-
Diaphragm Pump
-
Power:
-
Electric
-
Outlet Port Materials:
-
Barbed Fitting/1'' Stainless Steel Threaded Connector
-
Amps:
-
12.9A/6.5A
-
Maximum Submerion:
-
100 Feet Maximum (30m)
-
Usage:
-
Field Irrigation
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
DEMUDA
-
Model Number:
-
sp-12v24v
-
Application:
-
Outdoor Garden Agriculture Irrigation Deep Well
-
Material:
-
Plastic + Alloy
-
Horsepower:
-
100psi / 7.0 Bar
-
Voltage:
-
12V 24V DC
-
Product name:
-
Solar Water Pump
-
Motor:
-
Permanent Magnet, Thermally Protected
-
Structure:
-
Diaphragm Pump
-
Power:
-
Electric
-
Outlet Port Materials:
-
Barbed Fitting/1'' Stainless Steel Threaded Connector
-
Amps:
-
12.9A/6.5A
-
Maximum Submerion:
-
100 Feet Maximum (30m)
-
Usage:
-
Field Irrigation
Product Description
12V/24V
Solar Water Pump for Irrigation
1.
【Low Noise and Silent Operation】
The water pump operates at a noise level of 50-55 decibels, providing a quiet and peaceful environment. When fixedly installed, the running noise is even lower.
2.
【High Lift Capacity】
The water pump can achieve a vertical lift of up to 70 meters, making it suitable for various applications requiring high lift capacity.
3.
【High-Temperature Resistance】
With a maximum medium temperature of 70°C, the water pump is designed to withstand high-temperature environments.
4.
【Reliable and Guaranteed】
All products have undergone CE certification and are equipped with multiple protection devices, ensuring their safety and reliability.
5.
【Convenient to Use】
The water pump is compact in size, easy to assemble and disassemble, allowing for quick and convenient installation and use.
6.
【High-Quality Diaphragm】
The water pump features a high-quality diaphragm, ensuring excellent performance and long service life.
7.
【 Imported Santoprene Material】
The water pump is made from original imported Santoprene granules, which are FDA approved for food contact and known for their high purity and durability.
8.
【 PA66+30% Glass Fiber Material】
The pump body is made of PA66+30% glass fiber material, providing high strength, pressure resistance, and preventing leaks.
9.
【Pure Copper Motor】
The water pump is equipped with a pure copper motor, which enhances efficiency, durability, and stability.
10.
【Energy-Efficient】
The water pump has low power consumption while delivering high performance, resulting in cost savings and reduced reliance on outdoor power sources.
11.
【Wide Application】
The water pump is suitable for a wide range of applications, making it versatile and adaptable to various water extraction needs.
12.
【 Compact Design】
The water pump has a maximum diameter of 10 centimeters, making it compatible with most small-diameter water extraction environments.
|
|
SP-12
|
SP-24
|
|
Voltage
|
Rated Voltage 12V
|
Rated Voltage 24V
|
|
Current
|
Rated Current 12.9A
|
Rated Current 6.5A
|
|
Flow Rate
|
Flow rate of 8 liters per minute
|
Flow rate of 8 liters per minute
|
|
Lift
|
Vertical lift of up to 70 meters
|
Vertical lift of up to 70 meters
|
|
Pressure
|
Pressure up to 7 kg/cm²
|
Pressure up to 7 kg/cm²
|
|
Power
|
Rated power of 155 watts
|
Rated power of 156 watts
|
|
Submersible Depth
|
Submersible depth of up to 30 meters
|
Submersible depth of up to 30 meters
|
|
Interface Outer Diameter
|
Connects to piping with inner diameter of 12/13mm
|
Connects to piping with inner diameter of 12/13mm
|
|
Size
|
Product size of 337*98*98mm
|
Product size of 337*98*98mm
|
|
Weight
|
Net weight/gross weight of 2.6/2.9kg
|
Net weight/gross weight of 2.6/2.9kg
|
|
Insulation Class
|
Insulation withstands temperatures up to 130°C, high temperature class B
|
Insulation withstands temperatures up to 130°C, high temperature class B
|
|
Applicable Well Diameter
|
Diameter of 100mm or above
|
Diameter of 100mm or above
|
