8 PIN SPST MARINE BOAT ON-OFF LED ROCKER SWITCH 12V 24V / MARINE Rocker Switch

1). Description: (12v led rocker switch Quick Details)

Max. Current: 20A DC
Max. Voltage: 24V DC
Avaliable power: 20A/12V 10A/24V DC
Dielectric intensity 1500V AC/5S
Insulation resistance: 100MΩ MIN
Contact resistance: 50MΩ MAX
Switch electrical functions : ON-OFF  (ON)-OFF  ON-ON  (ON)-ON  ON-OFF-ON  (ON)-OFF-ON  (ON)-OFF-(ON)  ON-ON-ON  ON-ON-OFF , (NO): MOM ON , Automatic reset ON.
Waterproof - IP68 .Material:ABS plastic panel .Waterproof and Anti-corrosion .
Carling Style ,Installation dimensions is : 21.2*37.2mm (the same as Carling style).
Approvals: CE,UL

2). Production Specification

1.100% test before shipment
2.more than 50000cycles life

3.High current rating to 20 amps

4.New style with rounded corners

5.Lighted and non-lighted

6.Maintain-action and momentary

7.High-quality circuit board and never use recycle plastic.

3). Advantages

All symbols are printed or laser etched directly onto the switch face using modern high tech inks and printers to ensure long image life. we do not use stickers which will wear off in a very short time.

The switch is rated at 20amp's however in ALL case we recommend that you wire the accessory through a fused relay.

1. more models for your choice

2. laser engravable logo for reference

1. Blister packing to protect switch well after long time shipment

2. Delivery time: within 5-15 days after confirming payment

3.2 Years warranty.

4.100% test the goods before packing.

5.OEM welcome.

6.100% manufacturing factory

7.CE UL approved

8.Waterproof IP68

We have five years of experience in rocker switch\switch panel manufacturing industry, our products pass CE RoHs IP test,and our products has China patent, We get a good reputation of quality control and complete facilities.
We regard "good customer service, good business reputation and good quality control" as our service faith. Under the enterprise spirit of "honestly cooperation and continual innovation", we will continually improve products and services.

Welcome to visit our factory anytime, we can show you our production line,and your will know how to produce a switch or switch panel.
