Quick Details
-
Control System Brand:
-
Cypcut
-
Cutting Area:
-
20-360mm
-
Cutting Thickness:
-
Please inquire for details
-
Control Software:
-
cypcut
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Magick/OEM
-
Weight (KG):
-
26000 KG
-
Configuration:
-
other
-
Name:
-
fiber laser tube cutting machine
-
Laser power:
-
1-12kw
-
Pipe Cutting Thickness::
-
Depends on Material
-
Cutting speed:
-
Max 0.8s/cut(Depending on material thickness)
-
Laser head:
-
Raytools Cutting Head
-
Cooling system:
-
Industry water chiller
-
Y axis single feeding length:
-
1200mm
-
Z axis adjustment range:
-
65mm
-
W axis adjustment range:
-
360°
-
Machine repeat positioning accuracy:
-
±0.03mm
Quick Details
-
Laser Type:
-
Fiber Laser
-
Cutting Speed:
-
60 m/min
-
Cooling Mode:
-
WATER COOLING
-
Control System Brand:
-
Cypcut
-
Cutting Area:
-
20-360mm
-
Cutting Thickness:
-
Please inquire for details
-
Control Software:
-
cypcut
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Magick/OEM
-
Weight (KG):
-
26000 KG
-
Configuration:
-
other
-
Name:
-
fiber laser tube cutting machine
-
Laser power:
-
1-12kw
-
Pipe Cutting Thickness::
-
Depends on Material
-
Cutting speed:
-
Max 0.8s/cut(Depending on material thickness)
-
Laser head:
-
Raytools Cutting Head
-
Cooling system:
-
Industry water chiller
-
Y axis single feeding length:
-
1200mm
-
Z axis adjustment range:
-
65mm
-
W axis adjustment range:
-
360°
-
Machine repeat positioning accuracy:
-
±0.03mm
MAGICK support custom models
Iterate and upgrade products continuously to empower the enterprise production.
1.The pipe clamping range is wide,Round tube φ10-φ10, and Square tube side length is 10 * 10mm-360mm * 350mm. Support the cutting of various shapes of pipe materials, such as I-beam, channel steel, angle steel, elliptical pipe, waist pipe, multi-deformed pipe,etc.
2.The unique industrial structure design gives it maximum stability and higher vibration resistance and damping quality. The compact spacing of 650mm ensures the agility of the chuck and the stability during high-speed driving.
3.Fixing the pipe effectively solves the deformation problem in the cutting operation of the long pipe.
4.The professional cutting software for processing various types of pipes. Through the collection and processing of various real-time information, it can achieve high-precision cutting and achieve higher efficiency processing.
5.Manually set the number and time interval of automatic lubrication according to the length of equipment use;Automatic lubrication of guide rails, sliders, gears, racks, and other components, recycling, and centralized processing of lubricating waste oil.
2.The unique industrial structure design gives it maximum stability and higher vibration resistance and damping quality. The compact spacing of 650mm ensures the agility of the chuck and the stability during high-speed driving.
3.Fixing the pipe effectively solves the deformation problem in the cutting operation of the long pipe.
4.The professional cutting software for processing various types of pipes. Through the collection and processing of various real-time information, it can achieve high-precision cutting and achieve higher efficiency processing.
5.Manually set the number and time interval of automatic lubrication according to the length of equipment use;Automatic lubrication of guide rails, sliders, gears, racks, and other components, recycling, and centralized processing of lubricating waste oil.
Specification
|
Model
|
MK-12036T3C
|
|
Chuck moveable
|
3 (front +middle + rear chuck)
|
|
Effective Cutting Diameter Of Round Tube
|
Φ20-Φ350mm
|
|
Effective Cutting Diameter Of Square Tube
|
20-250mm
|
|
tailing length
|
≥0mm(with accracy)
|
|
holder
|
automatic with 6 pieces servo
|
|
unloader
|
yes support tube length 3000-12500mm
|
|
Repeat Positioning Accuracy
|
±0.03mm
|
|
Maximum Acceleration
|
0.5G
|
|
unloader
|
12.5m with 6 pieces servo
|
|
semi automatic loader
|
yes support tube length 3000-12500mm
|
Product Details
Double Chuck Clamping
Clamping round tube 10-160 mm.
Servo Motor and reducer are driven synchronously to enssure processing accurcay Both front and rear chucks are pneumatically tightened
Gear Drive
High Transmission efficiency, high accuracy, stable and long service life.
Stable Machine Bed and Gantry Structure
Machine bed and the gantry structure adopt plate welding structure After heat treatment and annealing to remover stress, the structure is stable and the rigidity is good
Laser Source
Different brands, different laser power are available. The higher power, the thicker cutting thickness.
3 pieces of protection lens, highly effective protection of collimating focus lens. 2-way optical water cooling, effectively extending the continuous working time.
Japan Shimpo
Dual cooling function
Real-time alarm
Machine protection
Taiwan - APEX
High precision
Accurate instantaneous transmission ratio
High transmission efficiency;
Long life
Applications Industry and Samples
Metal processing industry
Machinery processing
Aerospace industry
Medical instrument industry
Air conditioning industry
Kitchenware industry
Advertising industry
Garden decoration industry
Outdoor decoration industry
