- Product Details
- {{item.text}}
Quick Details
-
Description:
-
AV OVER IP based Matrix switcher
-
Video interface:
-
1xHDMI
-
Certifications:
-
CE CCC ISO9001 ISO14001
-
Resolution:
-
Up to 1080 @ 60Hz
-
Output video type:
-
IP stream
-
Control method:
-
PC,I-pad
-
External port:
-
1xRS232, 1xIO/IR
-
MOQ:
-
1 Pcs
-
Power supply:
-
DC12V
-
Warranty:
-
1 year
Quick Details
-
Brand Name:
-
Kensence
-
Model Number:
-
MST-HDMI MSR-HDMI
-
Place of Origin:
-
Guangdong, China
-
Description:
-
AV OVER IP based Matrix switcher
-
Video interface:
-
1xHDMI
-
Certifications:
-
CE CCC ISO9001 ISO14001
-
Resolution:
-
Up to 1080 @ 60Hz
-
Output video type:
-
IP stream
-
Control method:
-
PC,I-pad
-
External port:
-
1xRS232, 1xIO/IR
-
MOQ:
-
1 Pcs
-
Power supply:
-
DC12V
-
Warranty:
-
1 year
Product Description
This product is an advanced universal coding technology,A distributed processor that realizes ultra high definition image compression processing and smooth and realistic high definition image quality output. High definition access, to achieve one to many, many to many, single screen multi screen display requirements. Audio, video and control signals pass through IP network for transmission, distribution and switching. Meet the needs of application scenarios such as exhibition halls, lecture halls, conference rooms, and variable spaces.
1. Support various audio and video scheduling controls such as buttons, clients and APIs;
2. Visual operation of the client, integrated peripheral control; support subtitles and logo display:
3. Support maximum resolution 1080P@60Hz (downward compatible);
4. Abundant peripheral interfaces, including RS232, IO, network, etc.;
5. Adopt advanced universal coding technology to realize long-distance real time high definition picture quality transmission over IP network;
6. Support unicast and multicast switching, more efficient and low utilization of bandwidth resources, large scale application under 100M network;
7. Support dual power supply mode, standard DC5.1x2.1 interface and IEEE802.3at protocol PoE power supply;
Specification
|
model
|
MSTHDMI
|
MSRHDMI
|
|
|
Input Video Port
|
1xHDMI
|
1xLAN
|
|
|
Brand Name
|
Kensence
|
|
|
|
Type of video
|
HDMI.4.HDCP.2
|
IP stream
|
|
|
Place of Origin
|
China
|
|
|
|
|
Guangdong
|
|
|
|
Video output port
|
1xLAN1xHDMI
|
1xHDMI
|
|
|
output video type
|
IP stream
|
HDMI.4,HDCP.2
|
|
|
Certifications
|
CE CCC ISO9001 ISO14001
|
|
|
|
Input audio type
|
HDMI is compatible with all audio formats supported by HDM2.0, including PCM.0/5.1/7.1, Dolby True HD, Dolby, Atmos, DTS-HD Master
Audio and DTSX; Audioln stereo |
LAN/Optical is compatible with all audio formats supported by HDMI.0 including PCM.0/5.1/7.1, Dolby True HD, Dolby Atmos, DTS-HD
Master Audio and DTS:X |
|
|
External Port
|
1xRS32,1xOIR
|
1xRS32,1xOIRxAudioout
|
|
|
Resolution
|
Maximum support 1080P60Hz backward compatible)
|
|
|
|
Control Method
|
PC software, iPad mobile terminal
|
|
|
|
MOQ
|
1 Pcs
|
|
|
|
Power supply
|
DC12V
|
|
|
|
Warranty
|
1 year
|
|
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
