Quick Details
-
Weight:
-
200 KG
-
Frequency:
-
220-280r/min
-
Noise level:
-
<75dB
-
Sieving Precision:
-
98%
-
Layers:
-
1 - 4 layers
-
Sieve mesh:
-
5 - 600 mesh
-
Material:
-
Stainless Steel/ Carbon Steel
-
Keyword:
-
Tumbler Sieve
-
Voltage:
-
110V 220V 230V 380V 400V 415V 440V 500V 600V 50HZ 60HZ
-
Local Service Location:
-
None
Quick Details
-
Type:
-
Circular
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
As per order
-
Weight:
-
200 KG
-
Frequency:
-
220-280r/min
-
Noise level:
-
<75dB
-
Sieving Precision:
-
98%
-
Layers:
-
1 - 4 layers
-
Sieve mesh:
-
5 - 600 mesh
-
Material:
-
Stainless Steel/ Carbon Steel
-
Keyword:
-
Tumbler Sieve
-
Voltage:
-
110V 220V 230V 380V 400V 415V 440V 500V 600V 50HZ 60HZ
-
Local Service Location:
-
None
Product Description
Detailed Images
Customizable construction deck
According to the needs of the buyer, the number of swing screen layers can be customized. At present, our factory supports the customization of one to four layer swing screen.
Customizable construction material
Stainless steel material is the first choice for medical grade and food grade buyers, carbon steel is the first choice for cost saving, contact with stainless steel can not only meet the health requirements, but also save costs.
Size information
|
Model
|
Screen mesh area (m²)
|
Frequency
(r/min)
|
Screen slope
(゜)
|
Granularity
size
(mm)
|
Amplitude
(mm)
|
Power
(kw)
|
|
CWYS-600
|
0.28
|
220-280
|
0-10
|
≤100
|
20-70
|
0.75
|
|
CWYS-1000
|
0.66
|
220-280
|
0-10
|
≤100
|
20-70
|
1.5
|
|
CWYS-1200
|
0.98
|
220-280
|
0-10
|
≤100
|
20-70
|
2.2
|
|
CWYS-1500
|
1.67
|
220-280
|
0-10
|
≤100
|
20-70
|
3.0
|
|
CWYS-1800
|
2.37
|
220-280
|
0-10
|
≤100
|
20-70
|
4.0
|
|
CWYS-2000
|
2.89
|
220-280
|
0-10
|
≤100
|
20-70
|
4.0
|
|
CWYS-2600
|
5.3
|
220-280
|
0-10
|
≤100
|
20-70
|
5.5
|
