Quick Details
-
Insulation Material:
-
PVC
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
RuiTian
-
Model Number:
-
Electrical Wires
-
Product name:
-
Electrical Wires
-
Color:
-
as customer require
-
Conductor:
-
copper
-
Insulation:
-
PVC
-
Rated Voltage:
-
300V/500V
-
certification:
-
CE CCC ISO
-
Colors:
-
Red\blue\white \ Yellow \green\brown\black\grey Customized
Quick Details
-
Application:
-
Overhead
-
Conductor Material:
-
Copper
-
Conductor Type:
-
Stranded
-
Insulation Material:
-
PVC
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
RuiTian
-
Model Number:
-
Electrical Wires
-
Product name:
-
Electrical Wires
-
Color:
-
as customer require
-
Conductor:
-
copper
-
Insulation:
-
PVC
-
Rated Voltage:
-
300V/500V
-
certification:
-
CE CCC ISO
-
Colors:
-
Red\blue\white \ Yellow \green\brown\black\grey Customized
High Quality Solid Single Copper Core Cables Electrical Wires For House Holding Wires
1.Product standard:
The production standard for anti-flaming and fire-resistant cables is GB/T19666-2005,GB/T5023-2008,JB/T8734-2012
2.Main of cables features
1,Uo/U is 450/750V,300/500,
2,Long-term allowable temperature of the cable:The allowable temperature of 105 Cable should not exceed 105℃, the allowable temperature of other models should not exceed 70℃.
3. Copper core PVC insulated electric cable
is a fine and ideal cable with conductor of plain annealed copper wires,solid or stranded.These cables are used for general purpose,as building wire for power, lighting and control wire to electrical appliances,suitable for use in conduit and for fixed,protected installation. The cable can be of flame ratardance,fire resistance and other property.
4. Application
a. Use as home appliance wiring cable, building wire
b. Use as electrical and electronic equipment internal connecting wire
c. Use as lighting wire
d. House wiring cable
| production name: |
High Quality Solid Single Copper Core Cables Electrical Wires For House Holding Wires |
| rated temperature: | 90°C 7 0°C |
| rated voltage: | 300/500V |
| Model: | BV/BVR/RV |
| Jacket material: | PVC |
| CORE Material: | copper |
| Insulating material: | PVC |
| cross section(mm2): | 1 1.5 2.5 4 6 10 16 25 35 50 |
| core : | 1 |
| Nominal cross section area | Nominal Insulation Thickness | Nominal Overall diameter | Approx Weight | Max. D.C. Resistance of Conductor (20°C) |
| mm2 | mm | mm | kg/km | Ohm/km |
| 1.5 | 0.7 | 2.9 | 22 | 12.1 |
| 2.5 | 0.8 | 3.6 | 32 | 7.41 |
| 4 | 0.8 | 4.1 | 50 | 4.61 |
| 6 | 0.8 | 4.7 | 71 | 3.08 |
| 10 | 1 | 5.9 | 110 | 1.83 |
| 16 | 1 | 6.8 | 164 | 1.15 |
| 25 | 1.2 | 8.4 | 256 | 0.727 |
| 35 | 1.2 | 9.4 | 346 | 0.524 |
| 50 | 1.4 | 11 | 473 | 0.387 |
| 70 | 1.4 | 12.7 | 674 | 0.268 |
| 95 | 1.6 | 14.7 | 913 | 0.193 |
| 120 | 1.6 | 16.2 | 1150 | 0.153 |
| 150 | 1.8 | 18 | 1461 | 0.124 |
| 185 | 2 | 20 | 1749 | 0.0991 |
| 240 | 2.2 | 23 | 2317 | 0.0754 |
| 300 | 2.4 | 25.2 | 3049 | 0.0601 |
| 400 | 2.6 | 28.4 | 3657 | 0.047 |
| 500 | 2.8 | 31.8 | 4700 | 0.0366 |
| 630 | 2.8 | 38.1 | 5890 | 0.0283 |
1).When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, pleasecall us or tell us in your e-mail so that we will regard your inquiry priority.
(2).How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.
(3).How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files,the samples will be ready for delivery in 37 days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express account orprepay us if you do not have an account.
(4).What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
