- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
S6700
-
Place of Origin:
-
Guangdong, China
-
Certification:
-
CE RoHS FCC
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
128Gbps
-
Model Number:
-
S6700
-
Place of Origin:
-
Guangdong, China
-
Certification:
-
CE RoHS FCC
UONEL CO LIMITED
Contact person:Natasha
Mobile/Whatsapp/Skype/Wechat:+86 13798264392
Website:www.uonel.com
www.uonel-telecom.com
https://uonel.en.alibaba.com
S6700 Series 10 GE Switches
High-performance, super-reliable 10 GE switches with comprehensive Quality of Service and security capabilities, ideal for use as access switches in large-scale data centers and core switches in campus networks.
Advanced switching architecture and line-card buffering ensure smooth, sustained performance; Huawei’s intelligent iStack virtualization technology enables both easy management and expandability. Tight integration with Huawei’s eSight NMS for efficient provisioning, reconfiguring, and administration.
S6700 Series switches are available in 24-port and 48-port S6700-EI models, for resilient IPv4 and smooth migration to IPv6 networking.
Specifications
|
Specifications |
S6700-24-EI |
S6700-48-EI |
|
Switching Capacity |
960 Gbit/s |
960 Gbit/s |
|
Forwarding Performance |
360 Mpps |
720 Mpps |
|
Port |
24 x GE SFP/10 GE SFP+ ports |
48 x GE SFP/10 GE SFP+ ports |
|
IPv4 Routing |
Static routing, RIPv1, RIPv2, ECMP, and URPF OSPF, IS-IS, and BGP VRRP Policy-based routing Routing policy |
|
|
Multicast |
Static Layer 2 multicast MAC address MAC-based multicast forwarding IGMP snooping and IGMP fast leave Multicast VLAN MLD snooping IGMP proxy Controllable multicast Port-based multicast traffic statistics IGMP v1/v2/v3 PIM-SM, PIM-DM, and PIM-SSM MSDP |
|
|
MPLS Features |
MPLS L3VPN MPLS L2VPN (VPWS/VPLS) MPLS-TE MPLS QoS |
|
|
QoS/ACL |
Rate limiting on packets sent and received by an interface Packet redirection Port-based traffic policing and two-rate, three-color CAR Eight queues on each port WRR, DRR, SP, WRR + SP, and DRR + SP queue scheduling algorithms Re-marking of the 802.1p priority and DSCP priority Packet filtering at Layer 2 to Layer 4, filtering out invalid frames based on the source MAC address, destination MAC address, source IP address, destination IP address, port number, protocol type, and VLAN ID Rate limiting in each queue and traffic shaping on ports |
|
|
Security |
DoS attack defense, ARP attack defense, and ICMP attack defense 802.1x authentication and limit on the number of users on an interface AAA authentication, RADIUS authentication, and TACACS authentication SSH v2.0 Hypertext Transfer Protocol Secure (HTTPS) CPU defense Blacklist and whitelist |
|
|
Interoperability |
VBST (Compatible with PVST/PVST+/RPVST) LNP (Similar to DTP) VCMP (Similar to VTP) For detailed interoperability certifications and test reports, click HERE. |
|
Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.
| Delivery Options | Estimated Delivery Time |
|---|---|
DHL
|
3-5 business days |
Fedex
|
3-5 business days |
By Sea
|
10-20 business days |
Notice:
Above mentioned information are just for your reference only,we will keep you posted for the tracking delivery schedule.There are two delivery options available for by air and by sea:
Deliver to port:
Uonel is responsible for transporting goods to port. All subsequent customs and transportation fees are the
responsibility of the buyer. Uonel will recommend trustworthy local freight forwarders to you.Uonel can facilitate the progress under buyer's permission and at buyer's expense.
Deliver to door:
Uonel will quote all destination charge prior once we have confirmed order.
Uonel is responsible for transporting goods to door after you have made the payment.
100% Low Price Guarantee:
Uonel provides high-quality products at low wholesale prices
100% Quality Assurance:
All items are ORIGINAL NEW and GENUINE only.
Free Technical Support:
Our FREE Huawei Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee:
You can contact our customer service team to exchange or return any product that you bought from us.
Flexible Secure Payment & Shipment:
Verified authorization: Mcafee Secure, VeriSign Secured
Return Material Authorization (RMA) Process
Standard Hardware Warranty Policy:
Original new sealed Huawei product: 1 Year
The Support Contacts:
If your Huawei products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
