Quick Details
-
Voltage:
-
220V/50Hz
-
Dimension(L*W*H):
-
1100*970*460mm
-
Weight:
-
160 KG
-
product name:
-
book binding sewing machine
-
the longest book:
-
320mm
-
max.book thickness:
-
55mm
-
melting time:
-
25min.
-
bindng speed:
-
250 books/hour
-
pressing paper mode:
-
automatic
-
push paper mode:
-
numerical control
-
gluing roller:
-
1 gluing roller
-
book cutting method:
-
small cutter+disk cutter
-
display:
-
digital
Quick Details
-
Type:
-
book binding sewing machine
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
XSHEEN
-
Voltage:
-
220V/50Hz
-
Dimension(L*W*H):
-
1100*970*460mm
-
Weight:
-
160 KG
-
product name:
-
book binding sewing machine
-
the longest book:
-
320mm
-
max.book thickness:
-
55mm
-
melting time:
-
25min.
-
bindng speed:
-
250 books/hour
-
pressing paper mode:
-
automatic
-
push paper mode:
-
numerical control
-
gluing roller:
-
1 gluing roller
-
book cutting method:
-
small cutter+disk cutter
-
display:
-
digital
book binding sewing machine
Features
1. Adopt of double channel structure, reduce running noise and long time work stable
2. Programming angle adjustment, adapt different cover width, which is good for back shape
3. Double glue tank design, independent side glue, suit for spine creasing
4. Completely gluing, forming more perfect
5. Large rubber wheel, knurling process, gluing motor full, even
Clamp structure design patent, driving by double motors, forming more stably
6. Cover position plate, convenience for larges of binding
7. All digital control panel, English or Chinese selection, easy to understand
8. Emergency stop button in accordance for CE standards
9. Indentation structure patent
All aluminum clamp board patent, suit for thin books
10. Hard metal disk cutter, slot cutter milling back evenly ,increase the bonding strength of glue
Technical data
| Model | XH55B-A4 | XH56B-A4 |
| The longest book | 320mm | 330mm |
| Max. book thickness | 55mm | 56mm |
| Melting time | 25min | 25min |
| Binding speed | 250books/hour | 280books/hour |
| Pressing paper mode | automatic | automatic |
| Push paper mode | numercial control | numerical control |
| Gluing roller | 1 gluing roller | 1 gluing roller+1 side gluing roller |
| Book cutting method | small cutter+disk cutter | small cutter+disk cutter |
| Display | digital | digital |
| Power | AC220V 1KW | AC220V 2KW |
| Weight | 160kg | 205kg |
| Dimension | 1100*970*460mm | 1300*970*490mm |
| Model | XH55B-A3 | XH56B-A3 | XH66B-A3 | XH67B-A3 |
| The longest book | 420mm | 460mm | 460mm | 460mm |
| Max. book thickness | 55mm | 56mm | 66mm | 66mm |
| Melting time | 25min | 25min | 25min | 25min |
| Binding speed | 250books/hour | 280books/hour | 350books/hour | 300books/hour |
| Pressing paper mode | automatic | automatic | automatic | automatic |
| Push paper mode | numerical control | numerical control | numerical control | numerical control |
| Gluing roller | 1 gluing roller | 1 gluing roller+1 side gluing roller | 3 gluing rollers+1 side gluing roller | 3 gluing rollers+1 side gluing roller |
| Book cutting method | small cutter+disk cutter | small cutter+disk cutter | small cutter+disk cutter | small cutter+disk cutter |
| Display | digital | digital | digital | digital |
| Power | AC220V 1KW | AC220V 2KW | AC220V 2KW | AC220V 2KW |
| Weight | 220kg | 220kg | 300kg | 380kg |
| Dimension | 1300*980*480mm | 1560*970*490mm | 1700*990*560mm | 1880*1000*680mm |
Machine detail
1. Provide technical support before & after sale
2. Provide 18 months warranty, if any part defective, we replace the part for free
3. Provide durable spare parts with factory price after warranty
4. OEM and customize design
5. Professional documents and strong seaworthy packaging.
