Quick Details
-
Color Print Speed:
-
Donot support
-
Max. Resolution:
-
203dpi/8dots/mm/ 300dpi/12dots/mm
-
Brand Name:
-
Urovo
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
Thermal Transfer Labels Printers
-
Rotation angle:
-
Font and barcode support 90,180,270 rotation
-
Media Width:
-
20~ 120 mm (0.78" ~ 4.72")
-
Media thickness:
-
0.06~0.254mm (2.36 ~ 10 mil)
-
Print command:
-
Campatible with TSPL, EPL, ZPL, ZPL II, DPL
-
Media roll diameter:
-
203 mm (8") OD
-
Weight:
-
9.65kg
-
CPU:
-
400MHZ, 32-bits, ARM9
-
Real Time Clock:
-
Standard
-
Use:
-
Receipt printer Mobile Printer
Quick Details
-
Interface Type:
-
Other
-
Max Paper Size:
-
108mm
-
Black Print Speed:
-
152mm/s
-
Color Print Speed:
-
Donot support
-
Max. Resolution:
-
203dpi/8dots/mm/ 300dpi/12dots/mm
-
Brand Name:
-
Urovo
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
Thermal Transfer Labels Printers
-
Rotation angle:
-
Font and barcode support 90,180,270 rotation
-
Media Width:
-
20~ 120 mm (0.78" ~ 4.72")
-
Media thickness:
-
0.06~0.254mm (2.36 ~ 10 mil)
-
Print command:
-
Campatible with TSPL, EPL, ZPL, ZPL II, DPL
-
Media roll diameter:
-
203 mm (8") OD
-
Weight:
-
9.65kg
-
CPU:
-
400MHZ, 32-bits, ARM9
-
Real Time Clock:
-
Standard
-
Use:
-
Receipt printer Mobile Printer
Details Images
Specification
|
D9000 SERIES
|
4" Industrial Thermal Transfer Labels Printers
|
|
|
|
|||
|
Model
|
D9000(203DPI)
|
D9000(300DPI)
|
D9000i(203DPI)
|
D9000i(300DPI)
|
|||
|
Type
|
Standard
|
Standard
|
Enhanced
|
Enhanced
|
|||
|
Resolution
|
8dots/mm (203DPI)
|
12dots/mm (300DPI)
|
8dots/mm (203DPI)
|
12dots/mm (300DPI)
|
|||
|
Print methods
|
Thermal transfer or direct thermal
|
|
|
|
|||
|
Maximum Print Speed
|
203mm(8”)/second
|
152mm(6”)/second
|
203mm(8”)/second
|
152mm(6”)/second
|
|||
|
Maximum Print Width
|
104 mm (4.1“)
|
108.4 mm (4.27“)
|
104 mm (4.1“)
|
108.4 mm (4.27“)
|
|||
|
Maximum Print Length
|
2,286mm (90“)
|
1,016mm (40“)
|
2,286mm (90“)
|
1,016mm (40“)
|
|||
|
CPU
|
400MHZ, 32-bits, ARM9
|
|
|
|
|||
|
RAM
|
128 MB SDRAM
|
|
256 MB SDRAM
|
|
|||
|
ROM
|
128 MB Flash Memory
|
|
256 MB Flash Memory
|
|
|||
|
Interface
|
-USB2.0 high-speed 480 Mbps
-Built-in BT 4.0 (factory pre-installed)
-USB Host 2.0, can be connected to the external scan gun or keyboard
-Ethernet port 10/100Mbps
-RS-232 serial port
-Built-in WIFI (factory pre-installed)
|
|
|
|
|||
|
Real Time Clock
|
Standard
|
|
|
|
|||
|
Beeper
|
Standard
|
|
|
|
|||
|
Peel Option
|
•Cutter •a peel dispenser
|
|
|
|
|||
|
Sensors
|
-Gap sensor (removable) -Ribbon Sensor
-Black mark sensor (removable) -Paper Sensors
-Print head out of position
|
|
|
|
|||
|
Adaptor
|
Adaptor
Input: AC 200-240V, 1.5A, 50-60Hz, Output: DC 24V, 5A, 120W |
|
|
|
|||
|
User Interface
|
-1 Power button
-2 buttons (paper walk & pause)
-1LEDs (work, error, ribbon status)
|
|
-1 Power button
-1 button (paper walk)
-1LEDs (work, error, ribbon status)
-Capacitive touch screen TFT LCD 4.3"
Color 272×480, with backlight
|
|
|||
|
Built-in font
|
-8-inch digital body
-Truetypefont engine (downloadable vector fonts)
|
|
|
|
|||
|
1D Barcode
|
Code 11, Code 39, Code 93, Code 128 (subsets A, B, C), UPC-A, UPC-E, UCC-128,
Codabar, EAN/JAN-8, EAN/JAN-13, Interleaved 2 of 5, ITF14, MSI Pleassy, PostCode, Telepen |
|
|
|
|||
|
2D Barcode
|
QR Code, Micro QR Code, PDF417, Micro PDF417, Grid Matrix, MaxiCode,
Aztec Code,Data Matrix |
|
|
|
|||
|
Rotation angle
|
Font and barcode support 90,180,270 rotation
|
|
|
|
|||
|
Print command
|
Campatible with TSPL, EPL, ZPL, ZPL II, DPL
|
|
|
|
|||
|
Ribbon Specifications
|
450 M long, max. OD 105 mm, 1” core (ink coated outside)
|
|
|
|
|||
|
Ribbon Width
|
Max.115mm (4.5”)
|
|
|
|
|||
|
Media Types
|
Continuous, die-cut, black mark, Folding, Self-Adhesive Labels,etc
|
|
|
|
|||
|
Media Width
|
20~ 120 mm (0.78“ ~ 4.72“)
|
|
|
|
|||
|
Media thickness
|
0.06~0.254mm (2.36 ~ 10 mil)
|
|
|
|
|||
|
Media Roll Size
|
25.4 mm ~ 76.2 mm (1” ~ 3”)
|
|
|
|
|||
|
Media roll diameter
|
203 mm (8“) OD
|
|
|
|
|||
|
Label Height
|
5~2,286 mm
(0.2’’ ~ 90’’)
|
5~1,016 mm
(0.2’’ ~ 40’’)
|
5~2,286 mm
(0.2’’ ~ 90’’)
|
5~1,016 mm
(0.2’’ ~ 40’’)
|
|||
|
Physical
|
255mm (W) * 265mm (H) * 425mm (D)
|
|
|
|
|||
|
Weight
|
9.65kg
|
|
|
|
|||
|
Environmental
|
Operating Temperature : 5 ~ 40°C, 25~ 85% non-condensing
Storage Temperature:: -40 ~ 60°C, 10 ~ 90%non-condensing
|
|
|
|
|||
* 400 MHz 32-bit ARM9 Processor
* 128 MB SDRAM & 128 MB Large Flash Memory
* Vector font: True type font
* Multi-compatible; Emulation: SPL, EPL, ZPL, ZPL II, DPL
* Bartender® Windows Driver & Label Design Software
* Offer Windows printer utility, Windows SDK and Android SDK.
