Quick Details
-
Application:
-
Dam, Landfill,etc
-
Design Style:
-
Industrial
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
BPM GEOSYNTHETICS
-
Model Number:
-
BPMGT
-
Type:
-
Geotextiles
-
Weight:
-
100-1000g
-
Width:
-
0.6-6m
-
Length:
-
50-200m
-
Material:
-
PP or PET
-
Color:
-
White, Black, Gray or as your request
-
Standard:
-
ASTM, GB
-
Certification:
-
ISO, BV, SONCAP
-
Function:
-
Protection, Reinforcement
-
Keyword:
-
Non-woven Geotextile Filter Fabric
Quick Details
-
Warranty:
-
More than 5 years
-
After-sale Service:
-
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection
-
Project Solution Capability:
-
total solution for projects
-
Application:
-
Dam, Landfill,etc
-
Design Style:
-
Industrial
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
BPM GEOSYNTHETICS
-
Model Number:
-
BPMGT
-
Type:
-
Geotextiles
-
Weight:
-
100-1000g
-
Width:
-
0.6-6m
-
Length:
-
50-200m
-
Material:
-
PP or PET
-
Color:
-
White, Black, Gray or as your request
-
Standard:
-
ASTM, GB
-
Certification:
-
ISO, BV, SONCAP
-
Function:
-
Protection, Reinforcement
-
Keyword:
-
Non-woven Geotextile Filter Fabric
PP/PET Non-woven Geotextile 500g/m2 Filter Fabric Geotextile Fabric for Retaining Wall
Geotextile Details
|
Weight |
100-1000g or As your request |
|
Width |
Within 0.6 - 6 m as your request |
|
Length |
50-200m or As your request |
|
Material |
PET , PP |
|
Color |
Black, White, Green, Gray or as your request. |
|
Type |
Woven or Nonwoven; Short or Long Fiber |
|
Package |
Double layers white woven geotextile ; or As your request |
|
Shipping Marks |
As your request or Neutral Packing |
|
Production Standards |
ASTM, GB, or A s your request |
Geotextile Technical Parameter
| No. | Item | Unit | GB Standard Specification | ||||||||||
| 100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | 800 | |||
| 1 | Weight Deviation | % | -8 | -8 | -8 | -8 | -7 | -7 | -7 | -7 | -6 | -6 | -6 |
| 2 | Thickness ≥ | mm | 0.9 | 1.3 | 1.7 | 2.1 | 2.4 | 2.7 | 3 | 3.3 | 3.6 | 4.1 | 5 |
| 3 | Width Deviation | % | -0.5 | ||||||||||
| 4 | Breaking Strength | kN/M | 2.5 | 4.5 | 6.5 | 8 | 9.5 | 11 | 12.5 | 14 | 16 | 19 | 25 |
| 5 | Breaking Elongation | % | 25-100 | ||||||||||
| 6 | CBR Tear Strength ≥ | kN | 0.3 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 | 2.7 | 3.2 | 4 |
| 7 | Sieve Size | mm | 0.07--0.2 | ||||||||||
| 8 | Vertical Permeability | cm/s | K x(10-1 --10-3) K=1.0~9.9 | ||||||||||
| 9 | Tear Strength ≥ | kN | 0.08 | 0.12 | 0.16 | 0.2 | 0.24 | 0.28 | 0.33 | 0.38 | 0.42 | 0.46 | 0.6 |
Products
Our Packing
Geomembranes are wrapped double layers woven geotextiles
and added two strips at both ends.
Geotextiles are wrapped double layers woven geotextile.
Of course, If you have any requests, we will package products as your request.
All products will be loaded container safely.
Our Certificates
We have obtained SASO, SONCAP, BV, ISO and other certificates.
And we also have passed DEKRA, Intertek, CNAS and other tests.
Our quality is reliable.
If you have any other test or certificate, we can do it for you.
