Quick Details
-
Panel Size:
-
320x160mm / 1.05x0.53ft
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
BM4/BM3/BM2.5/BM2
-
Pixel Pitch:
-
2/2.5/3/4mm, 2/2.5/3/4mm
-
Product name:
-
Small pitch led display
-
Pixel Matrix Per Sq.m:
-
250000
-
Pixel Configuration:
-
SMD2121
-
Brightness (nits):
-
500-900
-
Scan:
-
1/40
-
Module Dimension:
-
320x160mm / 1.05x0.53ft
-
Cabinet Dimension:
-
640x480mm / 2.10x1.57ft
-
Cabinet Weight:
-
7kg/(Die-casting Aluminum)
-
Cabinet Resolution:
-
320x240
-
Grety Scale(bit):
-
14
Quick Details
-
Application:
-
Indoor
-
Brand Name:
-
LEDFUL
-
Color:
-
FULL COLOR
-
Panel Size:
-
320x160mm / 1.05x0.53ft
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
BM4/BM3/BM2.5/BM2
-
Pixel Pitch:
-
2/2.5/3/4mm, 2/2.5/3/4mm
-
Product name:
-
Small pitch led display
-
Pixel Matrix Per Sq.m:
-
250000
-
Pixel Configuration:
-
SMD2121
-
Brightness (nits):
-
500-900
-
Scan:
-
1/40
-
Module Dimension:
-
320x160mm / 1.05x0.53ft
-
Cabinet Dimension:
-
640x480mm / 2.10x1.57ft
-
Cabinet Weight:
-
7kg/(Die-casting Aluminum)
-
Cabinet Resolution:
-
320x240
-
Grety Scale(bit):
-
14
Product Description
Product Paramenters
|
Model
|
BM1.2
|
BM1.5
|
BM1.6
|
BM1.8
|
BM2
|
BM2.5
|
BM3
|
BM4
|
|||||||
|
Pixel Pitch(mm)
|
1.25
|
1.53
|
1.66
|
1.86
|
2
|
2.5
|
3
|
4
|
|||||||
|
Pixel Matrix Per Sq.m
|
422500
|
422500
|
360000
|
288906
|
250000
|
160000
|
90000
|
62500
|
|||||||
|
Pixel Configuration
|
SMD1212
|
SMD1212
|
SMD1212
|
SMD1515
|
SMD1515
|
SMD1515
|
SMD2121
|
SMD2121
|
|||||||
|
Cabinet Resolution
|
415x312
|
415x312
|
384x288
|
344x258
|
320x240
|
256x192
|
192x144
|
160x120
|
|||||||
|
Power Con.(W/㎡) (Max / Avg)
|
600W/200W
|
600W/200W
|
600W/200W
|
580W/180W
|
580W/180W
|
550W/160W
|
450W/160W
|
450W/160W
|
|||||||
|
Refresh Rate (HZ)
|
≥3840
|
≥3840
|
≥3840
|
≥3840
|
≥3840
|
≥1920
|
≥1920
|
≥1920
|
|||||||
|
Brightness (cd/㎡)
|
500-900
|
|
|
|
|
|
|
|
|||||||
|
Module Dimension
|
320x160mm / 1.05x0.53ft
|
|
|
|
|
|
|
|
|||||||
|
Cabinet Dimension
|
640x480mm / 2.10x1.57ft
|
|
|
|
|
|
|
|
|||||||
|
Cabinet Material
|
Die Casting Aluminum
|
|
|
|
|
|
|
|
|||||||
|
Cabinet Weight
|
7KG
|
|
|
|
|
|
|
|
|||||||
|
Service Access
|
Front
|
|
|
|
|
|
|
|
|||||||
|
Grey Scale (bit)
|
14
|
|
|
|
|
|
|
|
|||||||
|
Viewing Angle (H/V)
|
140°/140°
|
|
|
|
|
|
|
|
|||||||
|
IP Rate
|
IP45
|
|
|
|
|
|
|
|
|||||||
|
Operation Temperature
|
-20℃ ~ +80°℃
|
|
|
|
|
|
|
|
|||||||
|
Input Voltage (AC)
|
110V / 220V
|
|
|
|
|
|
|
|
|||||||
