Quick Details
-
EINECS No.:
-
TQ2700000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Kafuter
-
Model Number:
-
K-5202
-
Type:
-
adhesive thermal conduction
-
Color:
-
Grey
-
Brand:
-
Kafuter
-
table dry time(minute):
-
≤30
-
operating temperature range(°C):
-
-60~280
-
thermal conductivity(w/(m.k)):
-
0.80
-
hardness(shore A):
-
45~55
-
shear strength(MPa):
-
≥1.5
-
tensile strength(MPa):
-
≥2.5
Quick Details
-
CAS No.:
-
67762-90-7
-
Other Names:
-
thermally conductive silicone
-
MF:
-
C3H9OSi.(C2H6OSi)n.C3H9Si
-
EINECS No.:
-
TQ2700000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Kafuter
-
Model Number:
-
K-5202
-
Type:
-
adhesive thermal conduction
-
Color:
-
Grey
-
Brand:
-
Kafuter
-
table dry time(minute):
-
≤30
-
operating temperature range(°C):
-
-60~280
-
thermal conductivity(w/(m.k)):
-
0.80
-
hardness(shore A):
-
45~55
-
shear strength(MPa):
-
≥1.5
-
tensile strength(MPa):
-
≥2.5
APPLICATION
This elastomer replace thermal conductive silicone grease or paste in filling and bonding of CPU, PCB, thyristor control modules, and high-power electronics modules with radiators(heat sinks), etc. This elastomer instead of traditional ways with its good use and low cost.
◆Preparation
Clean the surfaces by removing the rust, ash, and oil, etc.
◆Application
Pierce the opening with the tip of the cap. Fix the nozzle, and coat the surface evenly with the
adhesives, then assemble two parts.
◆Curing Condition
Put the surfaces in air to make it get full cure. The curing progress is from outer surface into
inner surface. The elastomer can get cure with the depth of 2~4mm in 24 hours (at room
temperature, 55% moisture), if the sections is too deep (especially the parts not easy to
contact with air) or the temperature is too low, the cure time will be extend.
Advise users preparing enough time to let elastomer get full cure in order to stable its
properties before the next disposing or packaging.
◆Attention
1. After the application, screw its nozzle tightly and store in dry and cool place for next time
using.
2. Some cured adhesives around the opening when you use it again, just remove the cured,
and use the uncured.
Q: Can I buy samples placing orders?
A: Yes.Please feel free to contact us. The sample is free, you only need to pay the shipping cost.
Q: Can you provide OEM service?
A: Yes, we can produce under your own brand name. Logo and packing design need to be provided so as to make customized brand name.
Q: What is your payment term?
A: T/T, Western Union, L/C and Paypal. This is negotiable.
Q: What is the shipping method?
A: It could be shipped by sea, by air or by express(EMS, UPS, DHL, TNT, FEDEX and ect).Please confirm with us before placing orders.
Q: What other products do you have?
A: In addition to our main products are UV glue and silicone sealant, epoxy resin AB glue, we also have many other products, such as acrylic acid AB glue, anaerobic glue,instant dry glue, Ms glue, polyurethane glue and other thousands of high-performance adhesives.
|
|
|
|
|
|
||||
