Quick Details
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Vanjoin
-
Model Number:
-
VJ-WP-WL
-
Specification:
-
1500-3000mm'610mm'(60,75,90,100,120,150,180mm)
-
surface panel:
-
reinforced calcium silicon board or cement calcium silicon board
-
core:
-
EPS , cement , fly ash (Sand)
-
fire rated partition:
-
2--4 hours
-
acoustic performance:
-
46db
-
Product Name:
-
Prefab House Wall Panel Mold Cement Price Prefabricated Wall Panel
-
Advantages 1:
-
heat insulation and preservation
-
Advantages 2:
-
eco-friendly , energy saving
-
Advantages 3:
-
quick installation ( install a 110m2 in 7 days by 3 workers)
-
Advantages 4:
-
lightweight
Quick Details
-
Project Solution Capability:
-
graphic design
-
Application:
-
Hotel
-
Design Style:
-
Modern
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Vanjoin
-
Model Number:
-
VJ-WP-WL
-
Specification:
-
1500-3000mm'610mm'(60,75,90,100,120,150,180mm)
-
surface panel:
-
reinforced calcium silicon board or cement calcium silicon board
-
core:
-
EPS , cement , fly ash (Sand)
-
fire rated partition:
-
2--4 hours
-
acoustic performance:
-
46db
-
Product Name:
-
Prefab House Wall Panel Mold Cement Price Prefabricated Wall Panel
-
Advantages 1:
-
heat insulation and preservation
-
Advantages 2:
-
eco-friendly , energy saving
-
Advantages 3:
-
quick installation ( install a 110m2 in 7 days by 3 workers)
-
Advantages 4:
-
lightweight
Specification
|
|
Specification
(mm)
|
Weight
(kg/m2)
|
Packing
(pcs/m2 per 20GP)
|
Application
|
|||
|
Vanjoin light
weight
energy-saving
Compound
sandwich
panels
|
2270x610x60
|
45~48
|
315pcs/436m2
|
Roof
|
|||
|
|
2270x610x75
|
50~53
|
252pcs/349m2
|
Interior wall
|
|||
|
|
2270x610x90
|
55~58
|
207pcs/287m2
|
Interior/Exterior wall
|
|||
|
|
2270x610x100
|
60~65
|
189pcs/262m2
|
Interior/Exterior wall
|
|||
|
|
2270x610x120
|
65~75
|
153pcs/212m2
|
Exterior wall
|
|||
|
|
2270x610x150
|
80~90
|
126pcs/175m2
|
Exterior wall
|
|||
|
|
Allowed Tolerance: Length±5mm; Width±2mm; Thickness±1mm; Diagonal±2mm
|
|
|
|
|||
Features＆Usage
Features of eps sandwich wall panel
1. Energy-saving
---heat resistance and thermal insulation
2. Light weight ---1/6 of traditional brick
3. environment-friendly ---100% not asbestos
4. Area-saving --- save 4 m² / 100 m² (compare with tradition building materials)
5. Waterproof and damp proof ---see photos below
6. Fire-proof --- 4 hours 1000 degree without damage; GB/T9987
7. Sound-insulation ---38dB for 60mm, 46dB for 150mm
8. Best hanging force ---single point hanging strength: 50kg
9. Anti-seismic and impact resistance --- anti-earthquake class 7
10. Heat Insulation and preservation ---temperature differences between indoor and outdoor 5 ℃
11. Thermal insulation
12. Fast/easy construction, Low Labor: two experienced workers 50-80 square meters/day
13. Long life usage: 70 years
2. Light weight ---1/6 of traditional brick
3. environment-friendly ---100% not asbestos
4. Area-saving --- save 4 m² / 100 m² (compare with tradition building materials)
5. Waterproof and damp proof ---see photos below
6. Fire-proof --- 4 hours 1000 degree without damage; GB/T9987
7. Sound-insulation ---38dB for 60mm, 46dB for 150mm
8. Best hanging force ---single point hanging strength: 50kg
9. Anti-seismic and impact resistance --- anti-earthquake class 7
10. Heat Insulation and preservation ---temperature differences between indoor and outdoor 5 ℃
11. Thermal insulation
12. Fast/easy construction, Low Labor: two experienced workers 50-80 square meters/day
13. Long life usage: 70 years
Project Case
Product packaging
Certifications
Vanjoin Team & Factory
Customer Photos
About our service
1. Free sample and catalogue can be provided.
2. Quotation, all information related about our eps sandwich wall panels.
3. Arranging production.
4. Packing and shipping.
5. Sending you necessary documents for your customs clearance.
6. Providing all necessary information and technical support for installation.
7. Engineer is available to go abroad to train your workers.
How about quality control?
We monitor every producing procedure, and we will check the quality before packing and shipping.
and we pass ISO 9001 quality control system.
Do you only supply eps sandwich panels?
Vanjoin Products:
1. Sandwich panel
2. Sandwich panel making machine
3. flexible soft ceramic tiles
4. soft ceramic tiles making machine
5. Accessories related our products
2. Quotation, all information related about our eps sandwich wall panels.
3. Arranging production.
4. Packing and shipping.
5. Sending you necessary documents for your customs clearance.
6. Providing all necessary information and technical support for installation.
7. Engineer is available to go abroad to train your workers.
How about quality control?
We monitor every producing procedure, and we will check the quality before packing and shipping.
and we pass ISO 9001 quality control system.
Do you only supply eps sandwich panels?
Vanjoin Products:
1. Sandwich panel
2. Sandwich panel making machine
3. flexible soft ceramic tiles
4. soft ceramic tiles making machine
5. Accessories related our products
