Quick Details
-
Brand Name:
-
JTSPEEDWORK
-
Reading distance:
-
10cm
-
Communication Interface:
-
SPI interface, I2C interface, Serial UART interface
-
Serial Port Baud Rate:
-
115200 bps no parity, 8 data bits, 1 stop bit
-
Power:
-
DC 5V
-
Reading Current:
-
100mA
-
Stand-by Current:
-
40mA
-
Application:
-
HF IFID reader
-
Size:
-
40*30mm
Quick Details
-
Frequency:
-
13.56Mhz
-
Protocol:
-
ISO 14443A
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
JTSPEEDWORK
-
Reading distance:
-
10cm
-
Communication Interface:
-
SPI interface, I2C interface, Serial UART interface
-
Serial Port Baud Rate:
-
115200 bps no parity, 8 data bits, 1 stop bit
-
Power:
-
DC 5V
-
Reading Current:
-
100mA
-
Stand-by Current:
-
40mA
-
Application:
-
HF IFID reader
-
Size:
-
40*30mm
Products Description
Warehouse Management;
Library Management;
Logistics Management;
Asset Management;
Marathon Racing Sport Management,ect.
|
Technical Parameters
|
|
|
|
Working frequency
|
13.56Mhz
|
|
|
Protocol
|
ISO 14443A/ISO 15693
|
|
|
Reading distance
|
10cm
|
|
|
Communication Parameters
|
|
|
|
Communication Interface
|
SPI interface, I2C interface, Serial UART interface
|
|
|
Serial port baud rate
|
115200 bps no parity, 8 data bits, 1 stop bit
|
|
|
Power Parameters
|
|
|
|
Power
|
DC 5V
|
|
|
Reading Current
|
100mA
|
|
|
Stand-by Current
|
40mA
|
|
|
Environmental Parameters
|
|
|
|
Working Temp.
|
-30℃～80℃
|
|
|
Storage Temp.
|
-40℃～90℃
|
|
|
Storage Humidity
|
5%～95%RH no condensation
|
|
|
Physical Parameters
|
|
|
|
Size
|
30x40mm
|
|
|
Weight
|
About 10g
|
|
|
Pin Definition
|
|
|
||
|
Pin
|
Name
|
Dec
|
||
|
1
|
CSN
|
SPI - NSS
|
||
|
2
|
SCK
|
SPI - SCK
|
||
|
3
|
MOSI
|
SPI - MOSI
|
||
|
4
|
MISO
|
SPI - MISO
|
||
|
5
|
RST
|
Reset Button
|
||
|
6
|
GND
|
Ground
|
||
|
7
|
3.3V
|
Module 3.3V power supply input, the input rated current ≥ 80mA current
|
||
