Quick Details
-
Table Travel (Y) (mm):
-
500
-
Dimension(L*W*H):
-
2400*2975*2840mm
-
Weight (T):
-
5.1 T
-
Table Travel (Z) (mm):
-
540
-
Positioning Accuracy (mm):
-
±0.004
-
Range of Spindle Speed(r.p.m):
-
0 - 10000 r.p.m
-
Spindle Motor Power(kW):
-
7.5/11
-
Max. Table Load(kg):
-
600 kg
-
Feed Speed(mm/min):
-
1 - 20000 mm/min
-
Rapid Feed Speed(m/min):
-
48m/min
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
ADLV/SMTCL
-
Voltage:
-
380/220 and customizable
-
Marketing Type:
-
Hot Product
-
Machining Capacity:
-
Heavy Duty
-
Table Travel:
-
120-660mm
-
Tool Holder Model:
-
MAS 403 BT40
-
Core components:
-
Bearing, Motor, Pump, Gear, PLC, Pressure vessel, Engine, Gearbox
Quick Details
-
Table Size (mm):
-
1000x550
-
Number of Axes:
-
3
-
Table Travel (X) (mm):
-
850
-
Table Travel (Y) (mm):
-
500
-
Dimension(L*W*H):
-
2400*2975*2840mm
-
Weight (T):
-
5.1 T
-
Table Travel (Z) (mm):
-
540
-
Positioning Accuracy (mm):
-
±0.004
-
Range of Spindle Speed(r.p.m):
-
0 - 10000 r.p.m
-
Spindle Motor Power(kW):
-
7.5/11
-
Max. Table Load(kg):
-
600 kg
-
Feed Speed(mm/min):
-
1 - 20000 mm/min
-
Rapid Feed Speed(m/min):
-
48m/min
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
ADLV/SMTCL
-
Voltage:
-
380/220 and customizable
-
Marketing Type:
-
Hot Product
-
Machining Capacity:
-
Heavy Duty
-
Table Travel:
-
120-660mm
-
Tool Holder Model:
-
MAS 403 BT40
-
Core components:
-
Bearing, Motor, Pump, Gear, PLC, Pressure vessel, Engine, Gearbox
|
Item
|
|
Unit
|
Specifications
|
|
|
Capacity
|
X axis travel
|
mm
|
850
|
|
|
|
Y axis travel
|
mm
|
500
|
|
|
|
Z axis travel
|
mm
|
540
|
|
|
|
Spindle nose to table surface
|
mm
|
120-660
|
|
|
|
Spindle nose to column surface
|
mm
|
640
|
|
|
Worktable
|
Table size (L×W)
|
mm
|
1000×500
|
|
|
|
Max load on the table
|
kg
|
600
|
|
|
|
T-slot size
|
mm
|
18×5
|
|
|
Spindle
|
Spindle speed
|
rpm
|
10000
|
|
|
|
Spindle taper/spindle shank
|
mm
|
7/24 taper
|
|
|
|
|
|
BT40
|
|
|
|
Spindle motor
|
kw
|
7.5/11
|
|
|
|
Maximum output torque
|
N.m
|
35.8/70
|
|
|
|
Spindle drive type
|
|
Synchronous tooth belt
|
|
|
Feed rate
|
X,Y,Z rapid traverse
|
M/min
|
48/48/48
|
|
|
|
Max cutting feed rate
|
M/min
|
20
|
|
|
A.T.C
|
Tool storage capacity
|
pc
|
Arm type 24
|
|
|
|
Max tool diameter
|
mm
|
150(80)
|
|
|
|
Max tool length
|
mm
|
250
|
|
|
|
Tool change time(T-T)
|
sec
|
2.5
|
|
|
Accuracy
|
Positioning accuracy X/Y/Z
|
mm
|
0.008/0.006/0.006
|
|
|
|
Repeatability positioning X/Y/Z
|
mm
|
0.005/0.004/0.004
|
|
|
Others
|
Overall dimensions(L×WxH)
|
mm
|
2400×3125×2840
|
|
|
|
Net machine weight
|
kg
|
5100
|
|
|
|
Total power requirment
|
KVA
|
18
|
|
Q1：Is your company a manufacturer?
A1：Yes, we are a machine tool manufacturer, and we sell our own products.
Q2：What’s your payment terms?
A2：FOB, 50% downpayment after placing a P/O, and 50% payment before shipment, which is also negotiable as
per customer’s requirements.
Q3：What’s your delivery time?
A3：The delivery time ranges from 60 days to 90 days, which depends on the specific machine and its specific configurations. Please contact us to confirm whether the machine you order is in stock or to be produced.
Q4：Can we pay by L/C or others ？
A4：Yes ,you can make the payment by T/T , l/C etc.
Q5：What’s your warranty period?
A5：12 months.
Q6：Can you provide China agent service for your clients?
A6：Yes, we can take a live video tour of the factory and help customers establish a partner to visit various urban areas in China.
Q7：
Can you supply other international popular items?
A7：Yes, because we are an integrated company of industry and trade, we are able to provide international hot items in addition to our own products.
