Setting Information
|
|
|
|
pixel pitch
|
3.91mm
|
|
|
voltage
|
AC110-220V
|
|
|
lamp
|
SMD2121
|
|
|
module size
|
250mm*250mm
|
|
|
scan
|
1/16 s
|
|
|
temperature
|
5000K
|
|
|
brightness
|
1000-3000cd/m2
|
|
|
warranty
|
2-5 years
|
|
|
1
|
HD small pixel LED display
|
P1.5625 / P1.667/ P1.923/ P2/P2.5
|
|
2
|
Hot rental LED display
|
P3 / P3.91 / P4 / P4.81 / P5/ P5.95
|
|
3
|
Outdoor fixed LED display
|
P4/P5 /P6 /P8 /P10 /P16 /P20
|
|
4
|
Controller System
|
Nova Star / LINSN /Colorlight /Listen
|
|
5
|
LED Lamp
|
Nation Star /Epistar /Kinglight
|
|
6
|
IC
|
MBI 5124/ MBI 5153
|
|
7
|
power supply
|
Meanwell / G-energy / CL/ Youyi
|
|
|
|
|
|
8
|
Pixel Pitch
|
3.91 mm
|
|
9
|
IP Grade
|
IP43
|
|
10
|
Cabinet kind
|
Die-casting Aluminum
|
|
11
|
Cabinet Size
|
500*500MM/500*1000mm
|
|
12
|
Cabinet Weight(KG)
|
8.75kg/ 17.5kg
|
|
13
|
Packaging dimension
|
980*570*730mm/ 1090*710*730mm
|
|
14
|
Pixel density
|
65536dots/m2
|
|
15
|
Color temperature
|
6000K--8000K
|
|
16
|
Viewing angle
|
H:140;V:140
|
|
17
|
Defect Rate
|
≤0.1‰
|
|
18
|
Average power/m2
|
300W/m2
|
|
19
|
Maximal power/m2
|
600W/m2
|
|
20
|
Brightness adjusted
|
256 grade by auto-optic/color &8 grade by hand
|
|
21
|
Input signal
|
RF,S-video,RGB,RGBHV,YUV,YC&Composition,etc
|
|
22
|
Life-span
|
96360 hours
|
|
23
|
Frame frequency
|
50/ 60 Hz
|
|
24
|
Refresh rate
|
1920Hz/ 3840Hz
|
|
25
|
Signal Input(with video processor)
|
HDMI, DVI, VGA, RF, S-Video, RGB, RGBHV, YUV, YC&Composition, etc.
|
|
26
|
Control Distance
|
120 m (no repeating); Optical fiber transmission: 0.5km- 10km
|
|
27
|
Systems Operating Platform
|
Windows XP, Win 7, Win8, Win8.1, Win10
|
1.Kinglight or Nation Star LED lamp is used in led module, 48 hours' module aging test and 72 hours' led screen aging test before packing.
2. It adopts die-cast aluminum box, which is not easy to be deformed, anti-corrosion, fast heat dissipation and prolong product service life.
3. Lightweight and easy to transport and install.
4. Stainless steel lock connection, more stable, stable and safe.
5.Has a large Angle, color uniformity, low failure rate and easy maintenance.
6. Die-cast aluminum disposable Compression molding, high precision, seamless splicing.
7. Professional aviation plug/flight connestor, beautiful and stable, low power loss.
