Quick Details
-
Voltage:
-
3ph-380v-50hz
-
Dimension(L*W*H):
-
2450*1400*2110
-
Weight:
-
1900 KG
-
Working Temperature Range:
-
5-20℃
-
Application:
-
Industrial Cooling Solutions
-
Compressor type:
-
Semi-sealed Screw
-
Refrigerant:
-
R134a/R407c/R410a
-
Evaporator type:
-
Stainless Steel 316 Shell Tube
-
Power supply:
-
380V/3pH /50Hz
-
Temperature range:
-
5~+20DegC
-
After Warranty Service:
-
Online Technical Support
-
Condenser:
-
High Efficient Finned Copper Tube
-
Cooling method:
-
air cooled cooling
-
Compressor Brand:
-
Handbell
Quick Details
-
Condition:
-
New
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Mgreenbelt
-
Voltage:
-
3ph-380v-50hz
-
Dimension(L*W*H):
-
2450*1400*2110
-
Weight:
-
1900 KG
-
Working Temperature Range:
-
5-20℃
-
Application:
-
Industrial Cooling Solutions
-
Compressor type:
-
Semi-sealed Screw
-
Refrigerant:
-
R134a/R407c/R410a
-
Evaporator type:
-
Stainless Steel 316 Shell Tube
-
Power supply:
-
380V/3pH /50Hz
-
Temperature range:
-
5~+20DegC
-
After Warranty Service:
-
Online Technical Support
-
Condenser:
-
High Efficient Finned Copper Tube
-
Cooling method:
-
air cooled cooling
-
Compressor Brand:
-
Handbell
Product Description
Famous brand compressor
The unit adopts semi-hermetic screw compressor of Germany BITZER or Taiwan HANBEL brand. The latest 5-6
patented screw rotor profile with excellent efficiency. Adjustable stepless or stepped capacity control, energy efficient, stable
and quiet operation. Compressor starts in stages to minimise the impact on electricity. Stable, safe and low vibration operation.
The most advanced high-precision patented manufacturing process. Built-in fully intelligent monitoring and protection functions,
including thermal motor temperature monitoring, phase sequence monitoring, manual reset lockout, oil temperature sensor.
Microprogramming Control System
LCD touch screen interface. Industrial Siemens PLC centralized control combined with compressor capacity control system, precisely
monitor. Integrated protection for low temperature, high/low pressure, anti-freezing, phase missing, anti-phase, overload, motor
over temperature, oil differential, flow switch, start up latency. Optional operation language, menu leading, unit running state
easy to adjust.
A wide range of refrigerants and power sources are available
patented screw rotor profile with excellent efficiency. Adjustable stepless or stepped capacity control, energy efficient, stable
and quiet operation. Compressor starts in stages to minimise the impact on electricity. Stable, safe and low vibration operation.
The most advanced high-precision patented manufacturing process. Built-in fully intelligent monitoring and protection functions,
including thermal motor temperature monitoring, phase sequence monitoring, manual reset lockout, oil temperature sensor.
Microprogramming Control System
LCD touch screen interface. Industrial Siemens PLC centralized control combined with compressor capacity control system, precisely
monitor. Integrated protection for low temperature, high/low pressure, anti-freezing, phase missing, anti-phase, overload, motor
over temperature, oil differential, flow switch, start up latency. Optional operation language, menu leading, unit running state
easy to adjust.
A wide range of refrigerants and power sources are available
Standard design charging R22 CFC-free R407C, R410A, R404A, R134A
available. Standard design is 380V-415V/50Hz 3pH. 380V~415V, 50HZ/60HZ, different designs are available according to customers'
requirements.
Easy installation, quality is assured
Compact structure, less space demand and light in weight, easy for transport and installation.
Completely wired, inspected and tested pre-delivery, saving installation time and cost.
available. Standard design is 380V-415V/50Hz 3pH. 380V~415V, 50HZ/60HZ, different designs are available according to customers'
requirements.
Easy installation, quality is assured
Compact structure, less space demand and light in weight, easy for transport and installation.
Completely wired, inspected and tested pre-delivery, saving installation time and cost.
Details
Specification
|
Model
|
|
MG-80C
|
MG-110C
|
MG-155C
|
MG-200C
|
MG-260C
|
MG-300C
|
MG-420CF
|
|||||||
|
Cooling capacity
|
Kcal/h
|
67940
|
93740
|
206131580
|
177160
|
220160
|
264020
|
364640
|
|||||||
|
|
kw
|
79
|
109
|
153
|
15355.3
|
256
|
307
|
424
|
|||||||
|
Power input
|
|
3PH-380V-50HZ
|
|
|
|
|
|
|
|||||||
|
Refrigerant |
Type
|
R22/R407C
|
|
|
|
|
|
|
|||||||
|
|
Control
|
Thermostatic expansion valve
|
|
|
|
|
|
|
|||||||
|
Compressor |
Type
|
Semi-Closed screw chiller
|
|
|
|
|
|
|
|||||||
|
|
Power（kw）
|
28
|
37
|
51
|
66
|
79
|
94
|
127
|
|||||||
|
Evaporator |
Type
|
High efficiency copper tube shell and tube type
|
|
|
|
|
|
|
|||||||
|
|
Water flow m³/h
|
14
|
19
|
26
|
35
|
44
|
53
|
73
|
|||||||
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
Inlet/Outlet
|
DN65
|
DN65
|
DN80
|
DN80
|
DN80
|
DN80
|
DN100
|
|||||||
|
Condenser |
Type
|
High efficiency hydrophilic aluminum foll finned type
|
|
|
|
|
|
|
|||||||
|
|
Flow（m3/h)
|
30000
|
40000
|
60000
|
80000
|
100000
|
120000
|
160000
|
|||||||
|
Protection System |
|
Compressor overheat protection, high/low pressure protection,phase missing/sequence protection, flow rate protection, anti-frozen
protection. |
|
|
|
|
|
|
|||||||
|
Dimension
|
L mm
|
2720
|
2450
|
3250
|
4050
|
4050
|
4950
|
4680
|
|||||||
|
|
W mm
|
1120
|
1400
|
1950
|
1950
|
1950
|
1950
|
2250
|
|||||||
|
|
H mm
|
1800
|
2100
|
2000
|
2000
|
2100
|
2100
|
2460
|
|||||||
|
Wight
|
kg
|
1800
|
1900
|
2480
|
3000
|
3100
|
3600
|
5000
|
|||||||
