Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2246*1197*2mm
-
Panel Efficiency:
-
19.3%
-
Cell Type:
-
Mono-crystalline
-
No. of cells:
-
144 half cell
-
Weight:
-
8.6kg
-
Junction Box:
-
IP68 Rated
-
Output Cables:
-
450mm
-
Power Tolerance:
-
0~+5w
-
Packaging Configuration:
-
66pcs/pallets
-
Certificate:
-
TUV/VDE/CE/IEC/ISO
-
Warranty:
-
25years
Quick Details
-
Cell size:
-
182mmx182mm
-
Brand Name:
-
SUNMAN
-
Model Number:
-
SMF100-520M
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2246*1197*2mm
-
Panel Efficiency:
-
19.3%
-
Cell Type:
-
Mono-crystalline
-
No. of cells:
-
144 half cell
-
Weight:
-
8.6kg
-
Junction Box:
-
IP68 Rated
-
Output Cables:
-
450mm
-
Power Tolerance:
-
0~+5w
-
Packaging Configuration:
-
66pcs/pallets
-
Certificate:
-
TUV/VDE/CE/IEC/ISO
-
Warranty:
-
25years
Product Parameters
|
STC
|
SMF520J-12X12UW
|
|
Maximum Power ( Pmax )
|
520
|
|
Maximum Power Voltage ( Vmp )
|
42.3
|
|
Maximum Power Current ( Imp )
|
12.31
|
|
Open-circuit Voltage ( Voc )
|
49.5
|
|
Short-circuit Current ( Isc )
|
13.56
|
|
Module Efficiency (%)
|
19.3
|
|
Operating Temperature
|
-40℃ to 85℃
|
|
Maximum System Voltage
|
1500V DC(IEC)
|
|
Maximum Series Fuse Rating
|
25A
|
|
Application Class
|
Class A
|
|
Power Tolerance
|
0/+5 W
|
|
Weight
|
8.6KG
|
|
Size
|
2246*1197*2mm
|
|
STC: Irradiance 1000W/m
2
,Cell temperature 25℃,AM=1.5
|
Tolerances of Pmax,Voc and Isc are within ±5%
|
Why Choose Us
Detailed Images
Applications
Packaging&Shipping
Related Products
FAQ
Q1: How to choose the right panel?
A1: Tell us your demand, then our sales will recommend a suitable panel for you.
Q2: How about the delivery time?
A3: Delivery time 7 days for sample; 15 days for bulk order.
Q3: What is the warranty for solar panels?
A4: We offer 25 years linear output power warranty.
Q4: How can I get better service from you?
A5: We have professional engineer team can give you best support based on your requirement. If you have any problems during using, we offer 24 hours online service and will solve your problem within 1 hour.
