Quick Details
-
Model Number:
-
LB2822
-
Mechanical Life:
-
200,000, 300,000 times
-
IP level:
-
IP65
-
Product name:
-
LB2822
-
Color:
-
Red Green Blue
-
Function:
-
ON-OFF
-
Application:
-
marine equipment car electrical appliances
-
Button color:
-
Gold/Silver/Black
-
Electrical Life:
-
50000times
-
Size:
-
28*22mm
-
Type:
-
Rocker switch
-
Voltage:
-
20A:250VAC
Quick Details
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
China
-
Brand Name:
-
LANBOO
-
Model Number:
-
LB2822
-
Mechanical Life:
-
200,000, 300,000 times
-
IP level:
-
IP65
-
Product name:
-
LB2822
-
Color:
-
Red Green Blue
-
Function:
-
ON-OFF
-
Application:
-
marine equipment car electrical appliances
-
Button color:
-
Gold/Silver/Black
-
Electrical Life:
-
50000times
-
Size:
-
28*22mm
-
Type:
-
Rocker switch
-
Voltage:
-
20A:250VAC
Specification
|
Mounting Aperture
|
28*22mm
|
|
Serial Number
|
CX Ship type metal switch
|
|
Head Shape
|
Rocker
|
|
switch combination
|
2NO/2NO2NC,Slow action double contact
|
|
Waterproof Level
|
IP65,IK10(Refer to GB/T 20138)
|
|
Heating Current
|
Ith:20A 250VAC
|
|
Working Environment
|
-40°C~+80°C (Non-vacuum state, without icing)
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Contact Resistance
|
≤50mΩ
|
