Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
deedo
-
Voltage:
-
380V 50hz 3phase
-
Dimension(L*W*H):
-
10500*2500*3500mm
-
Power (kW):
-
30
-
Weight:
-
5000 KG
-
Name:
-
plastic net making machine
-
Capacity:
-
10-30kg/h
-
Color:
-
Customized
-
Function:
-
making the plastic net
-
Raw material:
-
Pellets
-
Final product:
-
Packing net
-
Control:
-
Frequency control
-
Manpower Needed:
-
1 person
-
Screw diameter:
-
50-65mm
-
Usage:
-
Packing the fruit
Quick Details
-
Screw Design:
-
Single-screw
-
Screw L/D Ratio:
-
33:1
-
Screw Speed (rpm):
-
120 rpm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
deedo
-
Voltage:
-
380V 50hz 3phase
-
Dimension(L*W*H):
-
10500*2500*3500mm
-
Power (kW):
-
30
-
Weight:
-
5000 KG
-
Name:
-
plastic net making machine
-
Capacity:
-
10-30kg/h
-
Color:
-
Customized
-
Function:
-
making the plastic net
-
Raw material:
-
Pellets
-
Final product:
-
Packing net
-
Control:
-
Frequency control
-
Manpower Needed:
-
1 person
-
Screw diameter:
-
50-65mm
-
Usage:
-
Packing the fruit
Product Description
Plastic stretch net machine, also called as mesh bag machine, or vegetable and fruit mesh bag machine. This machine adopts frequency control, rotary mold and infrared ray energy-saving heater, and mesh bag cutting length is flexible to adjust, and it can apply to continuous automatic production making raw plastic material into mesh bag in one time shaping.
And this machine can produce different barrel mesh bag, plain net of different size, material and application, and is widely used to produce mesh bag for first class appliance air filter, mariculture, alcohol package, bath ball, fruit and vegetable package.
Details Images
Specification
|
Model
|
Diameter of screw
|
Production efficiency
|
Installed power
|
Machine weight
|
|
DDJ-50
|
Φ50mm
|
10-20kg/h
|
30KW
|
2.5Ton
|
|
DDJ-60
|
Φ60mm
|
20-30kg/h
|
40KW
|
3Ton
|
|
DDJ-70
|
Φ70mm
|
30-40kg/h
|
50KW
|
4Ton
|
|
Model
|
DDJ-50
|
|
Screw Material
|
38CrMoALA
|
|
Material
|
PE/PP
|
|
Product
|
Shower ball,fruit and vegetable packing net,flower net
|
|
Power
|
30KW
|
|
Screw diameter
|
50mm
|
|
Outside diameter barrel
|
105mm
|
|
Screw L/D
|
33:1
|
|
Manpower needed
|
1 person
|
|
Layout
|
10000*3000*2000mm
|
Final Product
Packing & Delivery
Certifications
Exhibition
FAQ
YOU MIGHT INSTERESTED IN FOLLOWING QUESTIONS
2. How do you assistant to install the machine on worksite?
We are experienced on turn-key project, engineer and technicians will assistant client on construction, installation,
commissioning.
3. How can I get spare parts for replacement in other countries?
Wearing parts like blades, it is necessary to buy with machine, other parts in stock could be delivery out by express if urgent or by sea within 5days.
4. Can I use mark machine with different LOGO and color?
Yes, please confirm details with sales.
5. Can your customers test the machines?
Before buying and after production before leaving factory, we test machine you interested or paid with specified materials, free of charge.
If you have any need ,pls feel free to contact with us.
1. Are you manufacturer or trading company?
We are a professional recycling machines manufacturer for more than 15years we supplying full technical support and solutions,timely and professional service, always effort on quality, honest, win-win business for every client.
We are a professional recycling machines manufacturer for more than 15years we supplying full technical support and solutions,timely and professional service, always effort on quality, honest, win-win business for every client.
2. How do you assistant to install the machine on worksite?
We are experienced on turn-key project, engineer and technicians will assistant client on construction, installation,
commissioning.
3. How can I get spare parts for replacement in other countries?
Wearing parts like blades, it is necessary to buy with machine, other parts in stock could be delivery out by express if urgent or by sea within 5days.
4. Can I use mark machine with different LOGO and color?
Yes, please confirm details with sales.
5. Can your customers test the machines?
Before buying and after production before leaving factory, we test machine you interested or paid with specified materials, free of charge.
If you have any need ,pls feel free to contact with us.
