Quick Details
-
Place of Origin:
-
Henan
-
Brand Name:
-
Kowloon Machinery
-
Voltage:
-
220/380V/Customize
-
Weight:
-
18000 , 6000kg - 29000kg
-
Marketing Type:
-
New Product 2024
-
Product name:
-
Paper Shredding Machine
-
Finished Products:
-
Paper Block
-
Raw material:
-
Old Corrugated Paper, Cardboard
-
Application:
-
Packing Industry/Paper Mill
-
Model:
-
JLSS1000/JLSS1200/JLSS1500/JLSS2000
-
Motor:
-
11kw -90kw
-
Gearbox:
-
2units,planetary type, gear transmission
-
Lubrication system:
-
With automatic oil lubricator
-
Rotor rotary speed:
-
8-18 rpm
Quick Details
-
Production Capacity:
-
5-20 t/h
-
Product Type:
-
Paper Recycling Machine
-
Processing Type:
-
Waste Paper
-
Place of Origin:
-
Henan
-
Brand Name:
-
Kowloon Machinery
-
Voltage:
-
220/380V/Customize
-
Weight:
-
18000 , 6000kg - 29000kg
-
Marketing Type:
-
New Product 2024
-
Product name:
-
Paper Shredding Machine
-
Finished Products:
-
Paper Block
-
Raw material:
-
Old Corrugated Paper, Cardboard
-
Application:
-
Packing Industry/Paper Mill
-
Model:
-
JLSS1000/JLSS1200/JLSS1500/JLSS2000
-
Motor:
-
11kw -90kw
-
Gearbox:
-
2units,planetary type, gear transmission
-
Lubrication system:
-
With automatic oil lubricator
-
Rotor rotary speed:
-
8-18 rpm
Products Description
Double Shaft Cardboard Shredder Cardboard Recycling Machine
The waste
cardboard shredder
is a special equipment for waste paper and waste board. The unique design idea and processing technology of the waste paper shredder can make any shape of waste corrugated paper, cardboard, newspapers, waste books, cartons, paper tubes, paper tubes, cardboards. Wait for the material to be quickly processed into small pieces and collected to ensure that there is no dust.
Technical Parameters
|
Model
|
JLSS1000
|
JLSS1200
|
JLSS1500
|
JLSS2000
|
|||
|
Motor
|
15kw+15kw
|
22kw+22kw
|
55kw+55kw
|
90kw+90kw
|
|||
|
Gearbox
|
2units,planetary type, gear transmission
|
|
|
|
|||
|
Shaft
|
solid shaft, made of 40Cr, hardened and tempered
|
|
|
|
|||
|
Shredder chamber (inner)
|
940x725mm
|
1120x1000mm
|
1450x1100mm
|
1920x1250mm
|
|||
|
Rotor rotary speed
|
8-18rpm
|
8-18rpm
|
8-18rpm
|
8-18rpm
|
|||
|
Blade
|
diameter 360mm
|
diameter 360mm
|
diameter 530mm
|
diameter 560mm
|
|||
|
Lubrication system
|
With automatic oil lubricator
|
|
|
|
|||
|
Dimension
|
3.2x1.3x2.3m
|
3.2x2x1.9m
|
4.9x2.8x2.8m
|
6x3.8x4.8m
|
|||
|
Weight
|
6000kg
|
12000kg
|
18000kg
|
29000kg
|
|||
Details Show
High Capacity
Cardboard Recycling Machine
The production of paper products regularly produces a lot of waste. The production waste or production surplus, for example in the form of paper bales, paper cuttings, paper rolls or paper sheets, presents many companies with logistical challenges. Industrial paper shredders reduce large volumes economically. The shredded pieces can be reintegrated into production processes after being re-pulped.
Kowloon Machinery industrial paper shredders make a great contribution to the economical shredding of paper and corrugated cardboard. Strong, robust drives and rotors specifically designed for shredding paper or cardboard also make it possible to process material that is difficult to shred. Our machines can handle all throughput requirements for post-consumer applications such as waste paper, cartons, files and documents, shipping packaging, and industrial production waste. This includes cardboard tubes, paper webs, paper rolls, edge trims, printing waste or paper bales.
Cardboard Shredder Features
1. Low speed, high torque rotor, cutting and shearing working principle suitable for both soft and hard materials;
2. Blades made of special alloy, different shape, thickness and cutting head quantity providing the optimum solution for different materials.
3. Siemens, abb, weg…etc quality motors are available for different customers’ options
4. Schneider, chint, siements…etc electrical components to ensure steady performance and realize machine 24hours running, also plc system is optional to enabling automatic reverse for overload protection and minimizing blades damages;
5. Individual electrical control panel with plc control system ensure the machine work properly and safety;
6. Detachable type cutting head on shredder blades, makes the maintenance and replacement of wearing parts easier and much shorten maintenance time.
7. Low speed, lower noise, workable in workshop and outdoor.
If you are interested in our production line, please do not hesitate to contact us and we will provide you with a tailor-made solution.
