Quick Details
-
Panel Size:
-
60x6cm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
KDS-IF-P1.25
-
Display Function:
-
Video image
-
Screen Dimension:
-
60x6cm
-
Tube Chip Color:
-
FULL COLOR
-
Usage:
-
Indoor
-
Pixels:
-
1.25mm
-
Brightness:
-
More than 600cd/sqm
-
module size:
-
15x5.625cm
-
refresh rate:
-
3,840Hz
-
input voltage:
-
ac 110~220v +10%
-
application:
-
mall and retail
-
Pixel Pitch:
-
1.25
Quick Details
-
Application:
-
Supermarket Retail Store
-
Brand Name:
-
kingdigitals
-
Color:
-
full oclor
-
Panel Size:
-
60x6cm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
KDS-IF-P1.25
-
Display Function:
-
Video image
-
Screen Dimension:
-
60x6cm
-
Tube Chip Color:
-
FULL COLOR
-
Usage:
-
Indoor
-
Pixels:
-
1.25mm
-
Brightness:
-
More than 600cd/sqm
-
module size:
-
15x5.625cm
-
refresh rate:
-
3,840Hz
-
input voltage:
-
ac 110~220v +10%
-
application:
-
mall and retail
-
Pixel Pitch:
-
1.25
Remote controller goods shelves screen/led shop sign/shop board led display
(1)Multiplied file formats, such as AVI, MOV, MPG, DAT, VOB are comprehensive, and also we have three display mode as VGA+VIDE and VGA. There are also interfaces for Sound signal and video signal.
| Parameter | Unit | Value |
| Pixel Pitch | mm | 1.25 |
| LED type | COB | |
| Brightness | nits | >600 |
| Pixel density | sqm | 640,000 |
| Viewing angle | angle | 176°H and 176°v |
| Lifetime | hour | 100,000 hrs |
| Power consumption | w/m 2 | average 180w/m 2 , max 400w/m 2 |
| Operation power voltage | HZ | 110-240 V / 50-60 Hz |
| Cabinet/size (W×H×D) | cm | 60x6 |
| Cabinet/display surface in sqm | m 2 | 0.036 |
| Cabinet Materia | die-casting aluminum Cabinet | |
| Cabinet weight: | kg | 0.7kg |
| IP rating | only indoor | |
| Processing | bit | 16bit |
| Refresh rate | HZ | 1,920HZ |
| Operating temperature | degree | -10-30 degree |
| Storage temperature | degree | -20-50 degree |
| Operation humidity | 35-85% | |
| Storage humidity | 10-90% |
|
HD-led-screen-display- mounted -in -the wall
|
kingdigitals-indoor-led-display-case-in-Laos
|
kingdigitals-indoor-commercial-led-video-screen
|
|
P6-LED-video-wall-project-indoor-full-color-
Republic
of
Lithuania
|
P5-LED-video-wall-project-full-color-
Argentina
|
HD-indoor-color-led-display-for-hotel-in-United Arab Emirates |
Warranty:
We guarantee all our displays, modules, parts for two full years. During this time, we will replace or amend all our goods for free if there is something wrong with them. We provide lifetime maintenance and charge only for the raw materials. We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory. We also provide the operation manual, software, test report and so on. Any associated CAD drawing on how to fix up the display and some other expert suggestion will be provided.
Technology Training:
1. We provide the technology training for free, which contains the operation training and maintenance training in the factory.
2. We will send our engineers to your country by negotiation.
Documents and Certification:
1. We provide the operation manual, software, test report and so on.
2. We can also provide all kinds of certification such as CE, UL and so on.
CAD Drawing and Fixing:
1. We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
2. We will send our engineers to your place if we are expected after our negotiation.
Additional service:
We provide you the forwarding information, and some other information ,such as flight box, structure information for your reference for free.
