Quick Details
-
Voltage:
-
220-380V, 220-380V
-
Power:
-
2.2KVA, 220V,50/60HZ,2.4KVA
-
Dimension(L*W*H):
-
(L)3770*(W)670*(H)1450mm, (L)3770*(W)670*(H)1450mm
-
Weight:
-
850
-
Products heigh:
-
Max.55mm
-
Packing speed:
-
50-230bags/min
-
Film roll width:
-
Max.250mm
-
Film roll length:
-
Max.280mm
-
The biggest roll diameter:
-
Max.300mm
-
Film Thinkness:
-
0.04-0.06mm
-
Packaging film material:
-
OPP/CPP,OPP/CE,MST/PE, PET ETC.
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OCPACK
-
Marketing Type:
-
Wet Wipe Packing Machine
-
Voltage:
-
220-380V, 220-380V
-
Power:
-
2.2KVA, 220V,50/60HZ,2.4KVA
-
Dimension(L*W*H):
-
(L)3770*(W)670*(H)1450mm, (L)3770*(W)670*(H)1450mm
-
Weight:
-
850
-
Products heigh:
-
Max.55mm
-
Packing speed:
-
50-230bags/min
-
Film roll width:
-
Max.250mm
-
Film roll length:
-
Max.280mm
-
The biggest roll diameter:
-
Max.300mm
-
Film Thinkness:
-
0.04-0.06mm
-
Packaging film material:
-
OPP/CPP,OPP/CE,MST/PE, PET ETC.
Applicable materials: spunlaced non-woven fabrics,hot-rolled non-woven fabricsand dust-free fabrics.The maximum fabric roll diameter is 1100mm, the maximumcloth roll width is 100-210 mm, and the inner diameter of paper core is 76.2mm.
The fold size of wet wipes is (30-145) in length *(30-75) mm in width.
The spreadsize of wet wipes is length (150-210)* width (100-180).
The packaging material is aluminum-plated film or aluminum foil film with a thickness of 0.07mm to 0.09 mm.
The size of the packaging bag can be designed according to the number of pieces in the package.
The packing size of wet wipes is (50-170) mm in length * (50-100)mm in width.
The spreadsize of wet wipes is length (150-210)* width (100-180).
The packaging material is aluminum-plated film or aluminum foil film with a thickness of 0.07mm to 0.09 mm.
The size of the packaging bag can be designed according to the number of pieces in the package.
The packing size of wet wipes is (50-170) mm in length * (50-100)mm in width.
Raw material rack
The width of rawmaterials can be adjusted, the tensile tension is automatically controlled, and the operation is simple and convenient
Cutting and conveying
Cutting size can be controlled by PLC touch screen and monitored digitally. Double inverter control, the bag length can be set.
Packing structure
Computer touch screen control panel; equipped with imported photoelectric eyes, high tracking accuracy, easy adjustment; equipped with date printing device.
Folding welding of packaging film
Equipped with imported photoelectric eyes, high tracking accuracy, easy adjustment; equipped with date printing device.
|
Capacity
|
60-120 bags/min
|
|
Bag sealing type
|
Four sides sealing
|
|
Bag size range
|
(L)40-125mm
(W)40-110mm
|
|
Tissue material
|
30-80g/m2 airlay paper,wet strength paper,spunlace nonwoven fabric
|
|
Packing material
|
Lamination film,paper,aluminium
|
|
Folding option
|
Max.10 folding vertical,4 folding horizontal
|
|
Liquid range
|
1-12 grams
|
|
Machine noise
|
≦64.9 DB
|
|
Air consumption
|
300-500ml/min, 0.6-1.0Mpa
|
|
Total Power
|
2.8KW
|
|
Power Supply
|
220/380V 50/60HZ
|
|
Machine weight
|
950kgs
|
|
Machine dimension
|
2700x2500x1800mm (LxWxH)
|
