Quick Details
-
Weight (KG):
-
4500
-
Machine Type:
-
Beading Machine
-
Raw Material:
-
Sheet / Plate Rolling
-
Power:
-
Hydraulic
-
Extra Services:
-
Welding / Brazing
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
length:
-
9500*1620*1800
Quick Details
-
Bending Length(mm):
-
8200 mm
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
LIMING
-
Weight (KG):
-
4500
-
Machine Type:
-
Beading Machine
-
Raw Material:
-
Sheet / Plate Rolling
-
Power:
-
Hydraulic
-
Extra Services:
-
Welding / Brazing
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
length:
-
9500*1620*1800
8.2 meter folding machine
| Types | Function | Payment term | Other function |
| 4m/6m/8.2m | Can fold steel panel into any obtuse angles | 30% deposit required | shearing &slitting |
General Parameter
1) For Steel sheet; Aluminum; Stainless steel
2) Thickness: Max.1.0mm
3) Feeding width: Max. 1000mm
4) Driven by Servo motor, pump motor: 0.82KW
5) Working length: 6000mm
6) Press clamp : 9 units
7) Weight : Approx. 4500 Kg
8) Pressing power : pump motor for hydraulic station 11KW ( Located outside )
9) Bending range : 0-125 degree
10) Depth of throat : 1000 mm ( Max. working width of material in clamp )
11) Hinge : 9 groups
9) Total power
:
12.92KW
(11KW+1.1KW+0.82KW)
10)Outline dimension
(
Length×Width×Height
):
9500×1620×1800 (For reference only)
Slitting Device
1)
Type Of Blade :
Slitting wheel
Diameter
:
80 (Enough)
Material
:
Cr12MoV
2)
Drive system
:
Motor driving, 1.1KW
Guiding device
:
Steel rope circling
3) Slitting speed : Approx.0.8m/s
Slitting distance: Through steel rope circulation.
Bending & Slitting Device
1) Max. Bending thickness 1.0mm
2) Max. Bending length 6000mm
3) Max. Slit thickness 1.0 mm
4) Min. folding dimension TBC
Hydraulic power pack
1) Capability : Max.16MPA
2) Capacity of oil tank : 460L
3) Power source : Hydraulic
PLC Control System
1) System : Siemens PLC Control
2) Numerical control locating system : Siemens PLC Control
3) Operating table : Touch Screen
4) Angle programmer : Encoder test
5) Slitting control : Manual
6) Emergency stop: e-stop button+ e-limit+ foot switch (right heavily)
8.2 meter type Machine Pictures:
<img height="178">
<img s" height="394">
We also have 4 meter and 6 meter two types for your selection.
Slitting wheels on folding machine
