Quick Details
-
Brand Name:
-
Deping
-
Voltage:
-
380
-
Power:
-
120kw
-
Dimension(L*W*H):
-
2650*1400*1665
-
Weight:
-
2000 kg
-
Warranty:
-
one year
-
Model:
-
welding pipe facing machine PFM1224 for automatic welding project
-
Pipe facing machine accurancy:
-
±0.05mm
-
Roughness:
-
Ra1.6
-
Efficiency:
-
10~40s
-
Power of pipe facing machine:
-
Supplied by hydraulic power unit
-
HPU:
-
motor type or diesel type
-
Bevel:
-
V shape, U shape, mixed shape, combined inner and outer bevel shape
-
Bevel speed:
-
105m/min
-
Feeding rate:
-
0.2~0.6mm/turn
-
Certification:
-
CE certificate
Quick Details
-
Pipe Material:
-
Carbon steel
-
Production Capacity:
-
1000
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Deping
-
Voltage:
-
380
-
Power:
-
120kw
-
Dimension(L*W*H):
-
2650*1400*1665
-
Weight:
-
2000 kg
-
Warranty:
-
one year
-
Model:
-
welding pipe facing machine PFM1224 for automatic welding project
-
Pipe facing machine accurancy:
-
±0.05mm
-
Roughness:
-
Ra1.6
-
Efficiency:
-
10~40s
-
Power of pipe facing machine:
-
Supplied by hydraulic power unit
-
HPU:
-
motor type or diesel type
-
Bevel:
-
V shape, U shape, mixed shape, combined inner and outer bevel shape
-
Bevel speed:
-
105m/min
-
Feeding rate:
-
0.2~0.6mm/turn
-
Certification:
-
CE certificate
1. Inner position clamping system of the automatic welding counter bore pipe facing machine (PFM) and duct edge facing for accuracy positioning, powerful clamping, safely and reliability;
2. Floating tool frame guarantee that duct cutting end accuracy is ± 0.05mm for the automatic welding counter bore pipe facing machine (PFM) ;
3. Hydraulic power unit to drive the automatic welding counter bore pipe facing machine (PFM) for on-site pipe end preparation and duct edge facing
4. Motor type hydraulic power unit is normally for onshore pipe laying barge, diesel type hydraulic power unit is for offshore used for the automatic welding counter bore pipe facing machine (PFM)
The automatic welding counter bore pipe facing machine (PFM) photo
