Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
YECHUANG
-
Model Number:
-
Y-IN-3.6KW
-
Input Voltage:
-
550V (160V~800V)
-
Output Voltage:
-
230/400Vac (Three phase)
-
Output Current:
-
21.7A
-
Output Frequency:
-
50hz/60hz
-
Size:
-
33*58*23 mm
-
Certificate:
-
CE RoSH
-
Warranty:
-
5years
-
Weight:
-
20.5KG
-
solar inverter:
-
hybrid inverter
-
solar energy:
-
on grid off grid
-
MPPT Efficiency:
-
98-99%
Quick Details
-
Output Type:
-
Single, Three Phase
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
97.6%
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
YECHUANG
-
Model Number:
-
Y-IN-3.6KW
-
Input Voltage:
-
550V (160V~800V)
-
Output Voltage:
-
230/400Vac (Three phase)
-
Output Current:
-
21.7A
-
Output Frequency:
-
50hz/60hz
-
Size:
-
33*58*23 mm
-
Certificate:
-
CE RoSH
-
Warranty:
-
5years
-
Weight:
-
20.5KG
-
solar inverter:
-
hybrid inverter
-
solar energy:
-
on grid off grid
-
MPPT Efficiency:
-
98-99%
Battery Input Data
Battery Type: Lead-acid or Lithium-ion
Battery Voltage: Range(V) 40-60V
Max. Charging Current(A) 120A 135A 190A 190A
Max.Discharging Current(A) 120A 135A 190A 190A
Charge Curve 3 Stages/Equalization
External Temperature Sensor Optional
Charging Strategy for Li-ion Battery Self-adaption to BMS
PV String Input Data
Max. Dc input power 6500w 7800W 9880W 10400W
Max. input voltage 370V(100V-500V)
MPPT Range 125-425V
Start-up Voltage 150V
PV input current 11A+11A 22A+11A 22A+22A 22A+22A
No.of MPPT tracker 2
No. of PV strings per MPP tracker 1+1 2+1 2+2 2+2
AC Output Data(AC)
Rated AC output and UPS power 5000W 6000W 7600W 8000W
Max.AC output power 5500W 6600W 8360W 8800W
Peak Power (off grid) 2 times of rated power,10 S
AC output rated current 20.8A 25A 31.7A/33A 33.4A/35A
Max. AC current 22.9A 27.5A 34.9A/36.3A 36.7A/38.5A
Max.Continuous AC Passthrough 35A 40A 50A 50A
Output Frequency and voltage 50/60Hz;120/240Vac(Split phase),208Vac(2/3 phase),230 Vac (single phase)
Grid Type Split phase; 2/3 phase, Single Phase
Current Harmonic Distortion THD<3% (Linear load<1.5%)
Efficiency
Max. Efficiency 97.60%
Euro Efficiency 97.00%
MPPT Efficiency 99.90%
Protection
PV Input Lighting Protection Integrated
Anti-islanding Protection Integrated
PV String Input Reverse Polarity Protection Integrated
Insulation Resistor Detection Integrated
Residual Current Monitoring Unit Integrated
Output Over Current Protection Integrated
Output Shorted Protection Integrated
Output Over Voltage Protection Integrated
Surge Protection DC Type II /AC Type II
Certification and Standards
Grid Regulation UL1741,IEEE 1547,RULE21.VDE0126,,AS4777,NRS2017,G98,G99,IEC61683,IEC62116,IEC61727
Safe Regulation IEC62109-1,IEC62109-2
EMC EN61000-6-1,EN61000-6-3,FCC15 class B
General Data
Operating Temperature Range -25℃~+60℃,>45℃ Derating
Cooling Smart cooling
Noise <30 dB
Communication with BMS RS485;CAN
Weight 32KG
Size (mm) 420WX670Hx233D
Protection Degree IP65
Installation Style Wall-mounted
Warranty 5 years
