Quick Details
-
Brand Name:
-
LPJ
-
Model Number:
-
M3*0.5
-
Thread inserts type:
-
Tailless thread sleeve
-
Customized support:
-
ODM
-
Product name:
-
self tapping thread insert
-
feature:
-
added flange
-
Specification:
-
M3*0.5
-
installation speed:
-
QUICK
-
Function:
-
operation of the equipment
-
characteristic:
-
improves production efficiency
-
Attributes:
-
reduce the failure rate
Quick Details
-
Material:
-
Stainless steel
-
Type:
-
Imperial (Inch)
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
LPJ
-
Model Number:
-
M3*0.5
-
Thread inserts type:
-
Tailless thread sleeve
-
Customized support:
-
ODM
-
Product name:
-
self tapping thread insert
-
feature:
-
added flange
-
Specification:
-
M3*0.5
-
installation speed:
-
QUICK
-
Function:
-
operation of the equipment
-
characteristic:
-
improves production efficiency
-
Attributes:
-
reduce the failure rate
Products Description
It solves the problem of slow installation speed of traditional screw sleeves. It also avoids the difficulty of controlling the installation handle during the installation process of traditional screw sleeves, causing bulges and easy breakage. The screws are not easy to install, which affects the normal operation of the equipment, and improves production efficiency. , reduce the failure rate of mechanical equipment
|
|
Number of screw rings
|
|
|
|
|
|
|
||||
|
specification
|
1D
|
1.5D
|
2D
|
2. 5D
|
3D
|
Outer diameter before installation
|
Drill diameter
|
||||
|
M2. 5*0. 45
|
3.6
|
5.9
|
8.2
|
10.5
|
12.8
|
3.2~3.5
|
2.6
|
||||
|
M3*0.5
|
4.2
|
6.8
|
9.4
|
12
|
14.6
|
3.7~4.0
|
3.1
|
||||
|
M4*0. 7
|
4
|
6.6
|
9.1
|
11.7
|
14.2
|
5.0~5.3
|
4.2
|
||||
|
M5*0.8
|
4.4
|
7.1
|
9.9
|
12.6
|
15.3
|
6.3~6.6
|
5.2
|
||||
|
M6*1
|
4.3
|
6.9
|
9.6
|
12.2
|
14.9
|
7.5~7.9
|
6.3
|
||||
|
M8*1. 25
|
4.8
|
7.7
|
10.6
|
13.5
|
16.5
|
9.8~10.1
|
8.3
|
||||
|
M10*1.5
|
5
|
8.1
|
11.2
|
14.2
|
17.3
|
12~12.5
|
10.4
|
||||
|
M12*1.75
|
5.3
|
8.4
|
11.6
|
14.8
|
18
|
14.3~14.8
|
12.4
|
||||
