- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
HONGFA
-
Model Number:
-
HF-C-15
-
External Size:
-
180*440*400MM or custom
-
Name:
-
19 inch 3U Full Aluminum Sheet Metal Enclosure
-
Material:
-
Full Aluminum Alloy
-
Color:
-
Silver or Custom Color
-
Application:
-
PCB Box
-
Function:
-
Install Circuit Board
-
Surface treatment:
-
Metal brushed
-
Structure:
-
Split
-
Feature:
-
Surface Electrical Power Junction Box
-
Customization:
-
Accept Enclosure Customized
-
Performance:
-
Strong
Quick Details
-
Protection Level:
-
IP55
-
Type:
-
Control Box
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HONGFA
-
Model Number:
-
HF-C-15
-
External Size:
-
180*440*400MM or custom
-
Name:
-
19 inch 3U Full Aluminum Sheet Metal Enclosure
-
Material:
-
Full Aluminum Alloy
-
Color:
-
Silver or Custom Color
-
Application:
-
PCB Box
-
Function:
-
Install Circuit Board
-
Surface treatment:
-
Metal brushed
-
Structure:
-
Split
-
Feature:
-
Surface Electrical Power Junction Box
-
Customization:
-
Accept Enclosure Customized
-
Performance:
-
Strong
Product Description
| Photo | Parameters | |
|
Brand | HONGFA |
| Type | Multiple sheet metal plate & Extruded aluminum profile, ABS junctor combination | |
| Model No. | HF-C-15 | |
| Material | Aluminum, Steel, ABS plastic | |
| Color | Gray+ or Custom | |
| Sizes (H*W*L) | 180*440*400MM | |
| Length/Depth | Custom | |
| NO. | Part name | Qty | Material |
| 1 | Extruded fixed column | 12 | Aluminum Extrudede Alloy 6063 |
| 2 | Pannel | 6 | Aluminum sheet metal plate |
| 3 | Junctor | 8 | ABS plastic |
| 4 | Screw (3M) | 40 | Steel |
Difference Sizes
| Model No.: | Handle | Sizes (LxMxH )mm |
| HF-C-2 | 90x280x220 | |
| HF-C-3 | 100x280x240 | |
| HF-C-4 | none | 100x300x280 |
| HF-C-5 | Yes | 120x320x280 |
| HF-C-6 | 120x380x320 | |
| HF-C-7 | Yes | 140x360x320 |
| HF-C-8 | Yes | 150x400x380 |
| HF-C-9 | 150x440x420 | |
| HF-C-10 | Yes | 160x400x360 |
| HF-C-11 | 160x360x320 | |
| HF-C-12 | 170x440x380 | |
| HF-C-13 | 170x440x420 | |
| HF-C-14 | 170x480x360 | |
| HF-C-15 | Yes | 180x440x400 |
| HF-C-16 | Yes | 200x440x400 |
Applications
Packaging & Shipping
Packaging Details:
Plastic bag for each unit; then a batch packed into export carton
Delivery time:
15-60 days after payment
