1. Reliable structure: It can resist the wind of 110KM/H.
2. Perfect anti-corrosion performance: The structure is made of cold-formed galvanized steel which is much better in corrosion resistance.
3. Short processing time: The mechanical mass production is easy to shorten the processing cycle.
4. sealing performance: The structures are hidden in the house and outer panels maintain a seamless connection with tongue and groove system.
5. Easy installation: The structures are connected by bolts and nuts, no welding at all which greatly shorten the construction period.
- Product Details
- {{item.text}}
Quick Details
-
Product name:
-
prefabricated prefab steel structure building
-
ISO Quality Certificate:
-
ISO9001:2008
-
ISO Environment Certificate::
-
ISO14001:2004
-
Keyword:
-
steel structure building
-
Drawing Design:
-
3D
-
Style:
-
Modern Simple
-
Door:
-
Sliding Door or aluminum door or as your demanding
-
Structure:
-
Steel Structure Frame Welded
-
Main structure:
-
Galvanized Light Steel Frames
-
Roof:
-
Sandwich Panel+ Decoration Ceiling
Quick Details
-
Place of Origin:
-
Beijing, China
-
Brand Name:
-
CDPH
-
Model Number:
-
ZA
-
Product name:
-
prefabricated prefab steel structure building
-
ISO Quality Certificate:
-
ISO9001:2008
-
ISO Environment Certificate::
-
ISO14001:2004
-
Keyword:
-
steel structure building
-
Drawing Design:
-
3D
-
Style:
-
Modern Simple
-
Door:
-
Sliding Door or aluminum door or as your demanding
-
Structure:
-
Steel Structure Frame Welded
-
Main structure:
-
Galvanized Light Steel Frames
-
Roof:
-
Sandwich Panel+ Decoration Ceiling
PRODUCT DESCRIPTION
Product Introduction
① Structural safety:
it can withstand the wind of Grade 11, and the structure can withstand the hurricane of Grade 17 after special treatment;
② Good anti-corrosion performance:
the structure is made of thin-walled hot-dip galvanized cold-formed steel, with good anti-corrosion performance;
③ Short processing cycle:
mechanization and mass production can be realized, which shortens the processing cycle;
④ Good sealing performance:
the structural frame is placed inside the wall top plate, and the external maintenance plates form a seamless connection;
⑤ Fast installation speed:
the structural system is fully bolted, without welding on site, greatly shortening the construction period;
⑥ Flexible design:
personalized design can be provided according to customer needs.
PRODUCT PARAMETERS
|
Product specification
|
Length
|
|
Can be customized according to need
|
||
|
|
Width
|
|
≤13000mm
|
||
|
|
Height
|
|
eaves height <4500mm for single storey
|
||
|
|
|
|
eaves height<7000mm for two storey
|
||
|
|
Roof Type
|
|
Double slope, slope of roof 1:5 single slope, single roof slope 1:20
|
||
|
|
Storey
|
|
1-3 storey
|
||
|
Design Parameters
|
Roof Dead Load
|
|
0.3KN/㎡
|
||
|
(standard)
|
Floor Dead Load
|
|
0.5KN/㎡ (standard) Special requirements can be individually customized
|
||
|
|
Floor Live Load
|
|
2.0KN/㎡
|
||
|
|
Roof Live Load
|
|
0.5KN/㎡
|
||
|
|
(Snow Load)
|
|
|
||
|
|
Wind Load
|
|
0.45KN/㎡
|
||
|
|
Anti-Seismic
|
|
8 degrees
|
||
|
Recommended function
|
Mainly used for office, dormitory, dining hall, recreation building, etc.
|
|
|
||
|
Structure
|
Column
|
|
C shape steel, metal code Q235-Q345, thesection depends on the building span..
|
||
|
|
Roof Beams
|
|
C shape steel combined beam, the sectiondepends on the building span. Metal code Q235-Q345
|
||
|
|
Floor Beams
|
|
C shape steel combined beam, the sectiondepends on the building span. Metal code Q235-Q345
|
||
|
|
Purlin
|
|
C120 steel, T=1.8mm, material Q235 * Special circumstances determine the size alone
|
||
|
|
Spray
|
|
All structures are hot-dip galvanized, which can increase the amount of galvanized according to climatic conditions to ensure
anti-corrosion effect |
||
|
Roof
|
Use Material
|
|
Colour steel sandwich panel
|
||
|
|
|
|
According to the functional characteristics, colour steel veneer can be used
|
||
|
|
Insulation
|
|
Polystyrene, fire rated B2
|
||
|
|
|
|
Glass wool, fire rated A grade
|
||
|
|
|
|
/
|
||
|
Wall
|
Material
|
|
colour steel sandwich panel
|
||
|
|
|
|
According to the functional characteristics, colour steel veneer can be used
|
||
|
|
Insulation
|
|
Polystyrene, fire rated B2
|
||
|
|
|
|
Glass wool, fire rated A grade
|
||
|
|
|
|
/
|
||
|
Door
|
Size
|
|
According to the need to determine the door size
|
||
|
|
Material
|
|
For office: laminated wooden door/aluminium alloy door,
|
||
|
|
|
|
For workshop: sandwich panel sliding door/electric lifting door.
|
||
|
Window
|
Type
|
|
Sliding window, casement window, top hung window
|
||
|
|
Frame Material
|
|
Standard: Steel
|
||
|
|
|
|
Option: colour steel/aluminium alloy/brokenBridge aluminium alloy
|
||
|
|
Glass
|
|
Standard: single glass
|
||
|
|
|
|
Matching: hollow window
|
||
|
Ceiling
|
Normal Room
|
|
Standard: waterproof gypsum board
|
||
|
|
|
|
Option: calcium silicate board/mineral wool acoustic boar/aluminium alloy ceiling tile (depending on function and climate
condition) |
||
|
|
water room
|
|
PVC, Aluminium composite panel
|
||
|
Floor
|
Overhead Ground
|
|
There is a room with a full bath, ordinary room wood floor, PVC floor leather
|
||
|
|
(standard 500mm high)
|
|
|
||
|
|
Floor
|
|
Water room non-slip floor tile, common room floor tile
|
||
|
The Second Floor
|
Normal Room
|
|
Wooden floor
|
||
|
|
Water Room
|
|
Overall bathroom (recommended)
|
||
|
Electricity
|
Can provide programs, design, construction technology services
|
|
|
||
|
|
Socket
|
|
Multifunctional socket(250V/10A)
|
||
|
|
|
|
Three flat pins socket (250V/16A)
|
||
|
|
|
|
Can be equipped with European, American, and Australian standards according to demand
|
||
|
|
Cable
|
|
BV-1.5mm² / BV-2.5mm² / BV-4mm²
|
||
|
|
Voltage
|
|
220/380V
|
||
|
|
Breaker
|
|
High segmentation miniature circuit breaker
|
||
|
Water System
|
We can offer the scheme/designing/construction technique services
|
|
|
||
|
|
Water Wupply
|
|
PPR
|
||
|
|
Drainage System
|
|
UPVC
|
||
PRODUCTION DETAIL PICTURE
R
estRoom
TOILET
Indoor Environment
Lounge
Conference Room
Ceiling
PROJECT CASES
Ivory Coast Abidjan Port Expansion Project
China Road and Bridge Project
Oman Project
Camp Project
Shandong 300000 t/a caprolactam project temporary office camp project
Packing & Delivery
Our seivice
1. Before production : if you are going to place order , and need we design for you ,just provide us your idea and photos we can design for you .
2. During production: we can take photos for your goods during process .
3. After finished goods: when loading container , we will take loading picture for you .
4. After sale: if you have any problem or questions about the goods , just let us know by anytime , we will reply you in soonest time .
1. Before production : if you are going to place order , and need we design for you ,just provide us your idea and photos we can design for you .
2. During production: we can take photos for your goods during process .
3. After finished goods: when loading container , we will take loading picture for you .
4. After sale: if you have any problem or questions about the goods , just let us know by anytime , we will reply you in soonest time .
FAQ
1. Q: How about your delivery time?
A: Normally, the delivery time is as follows: Prefab house: 20-25days, Container house: 15-20days, Steel structure: 25-30days, Villa: 30-35days.
2. Q: What about the Month Capacity?
A: Prefab house: 100,000m2, Container house: 400units, Steel structure: 2000tons, Villa: 100,100m2.
3. Q: What’s the minimum order?
A: Prefab house: 50m2, Container house: 3units, Steel structure: 200m2, Villa: 100m2.
4. Q: What is your package?
A: Container house is in flat pack. Other houses will be loaded into shipping containers(main structure and panels in bulk, door/ceiling/floor tiles/furniture in cartons, sanitary/electrical/plumbing/hardware/fittings/tools in wooden case ).
5. Q: What’s you payment terms?
A: Wire transfer or LC.
6. Q: What certificate do you have?
A: We have been awarded the certificate by CE, American building Code, ISO9001, ISO14001, OHSAS18001 and China Classification Society. Meantime, we have been inspected many times by TUV, SGS and BV for the factory and products.
7. Q: What kind of technical drawings could you provide?
A: We could provide three-view drawing, 3D picture, blueprint, foundation, plumbing, electrical, communication, fire alarm, installation, furniture and so on.
8. Q: What is the lifespan and warranty period?
A: The lifespan for Prefab house is 5 to 10year, Container house is 10-15years, Steel structure is 15-20years and Villa is 20-50years. The warranty period for all the house is 12months from the delivery.
9. Q: What the value added service do you have?
A: We have camp/community planning design, indoor and outdoor electrical/plumbing design, communication/fire alarm/security system supply, furniture/ electric appliance offer, etc.
10. Q: Could you supply the service of installation?
A: Yes, we have 80 experienced supervisors who could go to guide the installation at any time. Meanwhile, we have skilled installation team who could finish some turn-key projects.
2. Q: What about the Month Capacity?
A: Prefab house: 100,000m2, Container house: 400units, Steel structure: 2000tons, Villa: 100,100m2.
3. Q: What’s the minimum order?
A: Prefab house: 50m2, Container house: 3units, Steel structure: 200m2, Villa: 100m2.
4. Q: What is your package?
A: Container house is in flat pack. Other houses will be loaded into shipping containers(main structure and panels in bulk, door/ceiling/floor tiles/furniture in cartons, sanitary/electrical/plumbing/hardware/fittings/tools in wooden case ).
5. Q: What’s you payment terms?
A: Wire transfer or LC.
6. Q: What certificate do you have?
A: We have been awarded the certificate by CE, American building Code, ISO9001, ISO14001, OHSAS18001 and China Classification Society. Meantime, we have been inspected many times by TUV, SGS and BV for the factory and products.
7. Q: What kind of technical drawings could you provide?
A: We could provide three-view drawing, 3D picture, blueprint, foundation, plumbing, electrical, communication, fire alarm, installation, furniture and so on.
8. Q: What is the lifespan and warranty period?
A: The lifespan for Prefab house is 5 to 10year, Container house is 10-15years, Steel structure is 15-20years and Villa is 20-50years. The warranty period for all the house is 12months from the delivery.
9. Q: What the value added service do you have?
A: We have camp/community planning design, indoor and outdoor electrical/plumbing design, communication/fire alarm/security system supply, furniture/ electric appliance offer, etc.
10. Q: Could you supply the service of installation?
A: Yes, we have 80 experienced supervisors who could go to guide the installation at any time. Meanwhile, we have skilled installation team who could finish some turn-key projects.
