Quick Details
-
Brand Name:
-
GL
-
Switch mode:
-
DC pulse
-
Pulse width:
-
≥20ms
-
Operating pressure:
-
0.02Mpa-0.8Mpa
-
Media temperature:
-
1-75℃
-
Responding time:
-
Open ≤0.15s close≤0.5s
-
Leakage upon high water pressure:
-
1.2MPa without leakage
-
Leakage upon low water pressure:
-
0.02Mpa leakage≤0.1ml/min
-
Temp of working environment:
-
1℃~+60℃
-
Permssible limiting water pressure:
-
≤1.2Mpa
-
Storage humidity:
-
25%~95RH(NO condensation state)
Quick Details
-
Warranty:
-
1 year
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
SDF-S209A
-
Brand Name:
-
GL
-
Switch mode:
-
DC pulse
-
Pulse width:
-
≥20ms
-
Operating pressure:
-
0.02Mpa-0.8Mpa
-
Media temperature:
-
1-75℃
-
Responding time:
-
Open ≤0.15s close≤0.5s
-
Leakage upon high water pressure:
-
1.2MPa without leakage
-
Leakage upon low water pressure:
-
0.02Mpa leakage≤0.1ml/min
-
Temp of working environment:
-
1℃~+60℃
-
Permssible limiting water pressure:
-
≤1.2Mpa
-
Storage humidity:
-
25%~95RH(NO condensation state)
Products Description
|
Rated Voltage
|
DC6V
|
DC9V
|
DC12V
|
DC24V
|
|||
|
Coil Resistance
|
12Ω±5%(20°)
|
36Ω±5%(20°)
|
75Ω±5%(20°)
|
160Ω±5%(20°)
|
|||
|
Min current
|
266mA
|
250mA
|
140mA
|
134mA
|
|||
|
Switch mode
|
DC pulse
|
|
|
|
|||
|
Pulse width
|
≥20ms
|
|
|
|
|||
|
Operating pressure
|
0.02Mpa-0.8Mpa
|
|
|
|
|||
|
Media temperature
|
1-75℃
|
|
|
|
|||
|
Responding time
|
Open≤0.15s close≤0.5s
|
|
|
|
|||
