Quick Details
-
Board Size:
-
43x43mm
-
Model Number:
-
ak1025664
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
akeson
-
Copper Thickness:
-
1OZ
-
Min. Hole Size:
-
0.075MM(Layer drilling)
-
Min. Line Width:
-
3mil
-
Min. Line Spacing:
-
3mil
-
Surface Finishing:
-
Immersfion Gold
-
Product name:
-
Consumer Electronic Pcb Board
-
Solder Mask:
-
Green.Black.Red.Yellow.White.Blue
-
Test service:
-
100% Electrical Test
-
Layer:
-
1-40 Layers (include Rigid-Flex PCB)
-
PCB Item:
-
half hole PCB
-
PCB Assembly process:
-
Circuit Board-SMD-DIP-assembly
-
Material:
-
FR4/CEM-1/CEM-3/FR1/aluminum
-
Keywords:
-
Multilayer USB Charger pcb
-
Usage:
-
OEM Electronics
-
Standard:
-
IPC-A-610D IPC 6012 class2/class3
Quick Details
-
Number of Layers:
-
8-layer
-
Base Material:
-
FR-4
-
Board Thickness:
-
1.6mm
-
Board Size:
-
43x43mm
-
Model Number:
-
ak1025664
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
akeson
-
Copper Thickness:
-
1OZ
-
Min. Hole Size:
-
0.075MM(Layer drilling)
-
Min. Line Width:
-
3mil
-
Min. Line Spacing:
-
3mil
-
Surface Finishing:
-
Immersfion Gold
-
Product name:
-
Consumer Electronic Pcb Board
-
Solder Mask:
-
Green.Black.Red.Yellow.White.Blue
-
Test service:
-
100% Electrical Test
-
Layer:
-
1-40 Layers (include Rigid-Flex PCB)
-
PCB Item:
-
half hole PCB
-
PCB Assembly process:
-
Circuit Board-SMD-DIP-assembly
-
Material:
-
FR4/CEM-1/CEM-3/FR1/aluminum
-
Keywords:
-
Multilayer USB Charger pcb
-
Usage:
-
OEM Electronics
-
Standard:
-
IPC-A-610D IPC 6012 class2/class3
Consumer Electronic Pcb Board FR4 94vO electronic parts board double side half hole PCB for Multilayer USB Charger pcb
|
Type |
PCB |
FPC |
|
Scope |
Multilayers( 1 - 40layer ),HDI(4-20) |
Flex,Rigid Flex |
|
Multilayers |
1-40 layers, board thickness 8mil-126mil (0.2mm-3.2mm) |
4- 40 layers, board thickness 15mil-126mil (0.38mm-3.2mm) |
|
HDI Buried/Blind Via |
4-18 layers, board thickness 15mil-126mil(0.38mm-3.2mm) 1+N+1,2+N+2,3+N+3,Anylayer |
4-20 layers, board thickness 10mil-126mil(0.25mm-3.2mm) |
|
HDI |
/ |
1+N+1,2+N+2,3+N+3,Anylayer |
|
Flex & Rigid-Flex PCB |
/ |
1-8layers Flex PCB ,2-12layers Rigid-flex PCB HDI+Rigid-flex PCB |
|
Laminate |
Shengyi,EMC,ITEQ,Panasionic,Hitachi.... |
|
|
Soldermask Type(LPI) |
Taiyo,Goo’s,Probimer..... |
Taiyo,Goo’s,Probimer FPC..... |
if have Gerber file or enquire. please email is violet(at)akesoncircuit(dot)com(dot) cn
Products infomation
8 layer,
Material:FR4(Tg180) material,
PCB thickness:1.60mm thick,
Final copper:1 OZ finished copper on all layers,
Surface:ENIG surface finish,
Ttchnology:with hard gold finger at edge-board,
Solder mask:green solder mask,
with impedance control
6.0/7.0mil min w/s(line width/spacing),
min drill bit:0.20mm,
min BGA pad size:0.33mm
Deliverables
1/Quotes in 24 hours or less
2/Standard production leadtime of 20 working days (4 weeks)
3/Prototype leadtime of 5 to 10 working days (1-2 weeks)
4/Stack-ups and impedance simulation in 36 hours
5/Initial response to technical questions or quality concerns in 36 hours
6/DFM and EQ's prior to PO placement upon request
Quality system
1/Akeson has mature and stringent Q
2/100% AOI, 100% ET, 100% FQC + FQA
3/SPC and Cpk programs
4/Lean Manufacturing and 6S programs
5/Advanced inspection and lab equipment
6/Standard QA report with every shipment
7/RoHS and REACH Compliance
8/Conflict Minerals Compliance
Akeson circuit Co.,ltd
sales:violet shen
Tel:86075529974750
pohne/webchat:13410525760
skype: akesoncircuit-sale
