Quick Details
-
Marketing Type:
-
New Product 2023
-
Application:
-
construction of high-rise
-
Rated Lifting Moment:
-
2500KN
-
Span:
-
70m
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Tarzan
-
Weight (KG):
-
88000 kg
-
Max Working Radius (m):
-
70
-
Height (m):
-
70
-
Max Load (T):
-
12
-
Tip Load (T):
-
2.5
-
Main Material Specs (mm):
-
L200X208 Angle Steel Welding
-
Counter Weight (T):
-
17.6
-
Total Weight (T):
-
88
-
Radius-changing Speed (m/min):
-
0-0.7 frequency conversion
-
Total Motor Power (kw):
-
40
-
Mast Section Dimension (m):
-
2X2X3
Quick Details
-
Rated Loading Capacity:
-
12ton
-
Max. Lifting Height:
-
70
-
Showroom Location:
-
China
-
Marketing Type:
-
New Product 2023
-
Application:
-
construction of high-rise
-
Rated Lifting Moment:
-
2500KN
-
Span:
-
70m
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Tarzan
-
Weight (KG):
-
88000 kg
-
Max Working Radius (m):
-
70
-
Height (m):
-
70
-
Max Load (T):
-
12
-
Tip Load (T):
-
2.5
-
Main Material Specs (mm):
-
L200X208 Angle Steel Welding
-
Counter Weight (T):
-
17.6
-
Total Weight (T):
-
88
-
Radius-changing Speed (m/min):
-
0-0.7 frequency conversion
-
Total Motor Power (kw):
-
40
-
Mast Section Dimension (m):
-
2X2X3
Specification
|
Tower Crane Working Grade
|
|
A4
|
|
|
|
||||
|
Mechanisms Working Grade
|
|
Hoisting
|
|
M4
|
|
||||
|
|
|
Slewing
|
|
M5
|
|
||||
|
|
|
|
|
M4
|
|
||||
|
Rated Hoisting Moment (kN.m)
|
|
3110
|
|
|
|
||||
|
Max Hoisting Height (m)
|
|
Stationary
|
|
51.3
|
|
||||
|
|
|
Anchorages
|
|
240.3
|
|
||||
|
Working Radius (m)
|
|
Min Radius
|
|
3.75
|
|
||||
|
|
|
Max Radius
|
|
75
|
|
||||
|
Max Hoisting Capacity (t)
|
|
16
|
|
|
|
||||
|
|
Falls
|
2
|
|
4
|
|
||||
|
|
Lifting Capacity/ Speed (t/m/min)
|
4/75
|
8/37.5
|
8/37.5
|
16/18.75
|
||||
|
|
Power (kW)
|
60
|
|
|
|
||||
|
|
Speed (m/min)
|
0～100
|
|
|
|
||||
|
|
Power (kW)
|
11
|
|
|
|
||||
|
|
Speed（r/min）
|
0～0.6
|
|
|
|
||||
|
|
Stall Torque（N.m）
|
2×145
|
|
|
|
||||
|
Climbing Mechanism
|
Working Pressure (MPa)
|
31.5
|
|
|
|
||||
|
|
Speed (m/min)
|
0.45
|
|
|
|
||||
|
Total Power (kW)
|
|
86 (excluded Climbing System
|
|
|
|
||||
|
|
|
Climbing
|
|
|
14
|
||||
|
|
|
In Service
|
|
|
20
|
||||
|
|
|
Out of Service
|
|
0～20m
|
36
|
||||
|
|
|
|
|
20～100m
|
42
|
||||
|
|
|
|
|
100m～
|
46
|
||||
|
Working Temperature (℃)
|
|
-20～+40
|
|
|
|
||||
|
Power Supply
|
|
～380V/50Hz
|
|
|
|
||||
