Quick Details
-
Dimension(L*W*H):
-
11 cubic
-
Weight:
-
2800 KG
-
Place of Origin:
-
Henan, China
-
Voltage:
-
380v,3 phases
-
Power:
-
7.5kw
-
After-sales Service Provided:
-
Free spare parts
-
Name:
-
Bamboo Wood Toothpick Chopstick Incense BBQ Stick Making Machine
-
Raw material:
-
Raw Bamboo or Raw Wood
-
Application:
-
bamboo or Wood Toothpick Process Equipment
-
Type:
-
Toothpick Processing Equipment
-
Package:
-
Standard Wooden Case
-
Capacity:
-
800000 Pecs/8 Hours
-
Usage:
-
Making Toothpick or chopsticks
-
Shape of toothpick:
-
One Head Or Two-head Sharp Toothpick
-
Product name:
-
Bamboo and Wood product Making Product Line
Quick Details
-
Machinery Capacity:
-
800000 pieces per day
-
Brand Name:
-
Runxiang
-
Year:
-
2023
-
Dimension(L*W*H):
-
11 cubic
-
Weight:
-
2800 KG
-
Place of Origin:
-
Henan, China
-
Voltage:
-
380v,3 phases
-
Power:
-
7.5kw
-
After-sales Service Provided:
-
Free spare parts
-
Name:
-
Bamboo Wood Toothpick Chopstick Incense BBQ Stick Making Machine
-
Raw material:
-
Raw Bamboo or Raw Wood
-
Application:
-
bamboo or Wood Toothpick Process Equipment
-
Type:
-
Toothpick Processing Equipment
-
Package:
-
Standard Wooden Case
-
Capacity:
-
800000 Pecs/8 Hours
-
Usage:
-
Making Toothpick or chopsticks
-
Shape of toothpick:
-
One Head Or Two-head Sharp Toothpick
-
Product name:
-
Bamboo and Wood product Making Product Line
Production Line Bamboo Wood Toothpick Chopstick Incense BBQ Stick Making Machine
1:Process: the original bamboo - take the material saw off - cut bamboo - cut open the film set the width of the wire - bleach - drying - cut - length - polished - tidy - pick up the residual sign - sharpening - pick up Residual sign - packing - storage (factory)
2: The following 10, the production of two sharp toothpicks, 8 hours output of 600,000, about 80 kg.Need mechanical workers 5 to 7, men and women are not limited. Power use 380V industrial electricity,the normal production of electricity consumption per hour about 12 degrees. Increase the No. 9 machine 4,the output of 3 million.
3: users need to produce a sharp carved bamboo toothpick, then the No. 9 machine replaced.WS-641 sharpening machine (priced at 7300 yuan / Taiwan), 10 sets / sets of 8 hours output of 500,000,increase WS- 641 machine 5 units, the output of 3 million.
| Iterm | Name | Model | Weight(KG) | Size(mm) | Motor power |
| 1 | Sawing machine (Bamboo) | WS-791 | 58 | 1200*500*1050 | 1.5kw |
| 2 | Bamboo dissection machine | WS-04 | 650 | 3100*700*1250 | 4.0kw |
| 3 | flakers | WS-036 | 310 | 1300*650*1030 | 3.3kw |
| 4 | Bamboo filament shaping machine | WS-211 | 400 | 1000*650*1080 | 7.1kw |
| 5 | Bamboo filament set-size machine | WS-05C | 80 | 1400*660*880 | 0.75kw |
| 6 | Toothpick set-size machine | WS-741 | 125 | 850*650*900 | 3.37kw |
| 7 | Polishing machine | WS-543 | 130 | 1300*1100*1300 | 1.5kw |
| 8 | Toothpick sorting machine | WS-956 | 80 | 1000*1000*750 | 0.55kw |
| 9 | Toothpick sharpening machine | WS-642 | 210 | 1050*650*950 | 1.99kw |
| 10 | Multi-sharpen machine | WS-721 | 65 | 750*500*950 | 0.37kw |
Q1. Pre-sale service:
A1: Please offer us detail pouch size, filling capacity, speed request etc, Then will give you good quotation.
Q2. In-sale service:
A2: After placing order to our produce department, we will follow well your orders and inform you the production status. We will supply you photos
Q3. After-sale service:
A3: The machine will have one year warranty which will begin from the customer receive the machines. During the warranty year we will replace parts which are damaged (except man-make damage) to you.
Q4: Which products this machine line can make?
Toothpicks,sticks,chopsticks and so on.
Q5: How to install the machines?
A5: two ways: 1, customer send technician to our factory to learn how to adjust machine, we train them with free.
2, we can send our engineer abroad to adjust machine and train workers.
Q6: What to do if the machines don't work appropriately?
A6: Generally, you will find the solutions in the manual. But if still can not solve the problem, please contact with the after-sale service department or the sales person by email or phone. We will reply you within 24 hours.
