- Product Details
- {{item.text}}
Quick Details
-
Color:
-
orange,grey,green
-
Dimensions::
-
144mm x 47mm x 30mm
-
Weight:
-
227g
-
IP Rating:
-
IP67( Waterproof)
-
Reading Mode:
-
RFID 125 KHz
-
Reading distance:
-
3cm - 5cm
-
Communication:
-
Pogo pin USB(Drive-Free),15000 record uploading/min
-
Operating Temperature:
-
-40℃~+85℃
-
Battery:
-
3.7V/1150mAh rechargeable lithium batteries
-
Storage Capacity:
-
60,000 pieces
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
JWM
-
Model Number:
-
WM-5000V5
-
Color:
-
orange,grey,green
-
Dimensions::
-
144mm x 47mm x 30mm
-
Weight:
-
227g
-
IP Rating:
-
IP67( Waterproof)
-
Reading Mode:
-
RFID 125 KHz
-
Reading distance:
-
3cm - 5cm
-
Communication:
-
Pogo pin USB(Drive-Free),15000 record uploading/min
-
Operating Temperature:
-
-40℃~+85℃
-
Battery:
-
3.7V/1150mAh rechargeable lithium batteries
-
Storage Capacity:
-
60,000 pieces
Product Parameter
Specification
|
Dimension
|
|
144mm × 47mm × 30mm
|
|
|
|
|
|
||||||
|
Weight
|
|
200g
|
|
|
|
|
|
||||||
|
IP Rating
|
|
IP67
|
|
|
|
|
|
||||||
|
Reading Mode
|
|
RFID 125KHz
|
|
|
|
|
|
||||||
|
Reading distance
|
|
3cm - 5cm
|
|
|
|
|
|
||||||
|
Communication
|
|
Pogo pin USB(Drive-Free),15000 record uploading/min
|
|
|
|
|
|
||||||
|
Operating Temperature
|
|
-40℃~+85℃
|
|
|
|
|
|
||||||
|
Battery
|
|
3.7V/880mAh rechargeable lithium batteries
|
|
|
|
|
|
||||||
|
Batter Life
|
|
1. Reading 1 record/sec, for 40 hours using.
2. Reading 500 record/day, for 30 days using. |
|
|
|
|
|
||||||
|
Storage Capacity
|
|
16Mbit flash, 60,000 pieces
|
|
|
|
|
|
||||||
|
Prompt
|
|
Vibration with Colorful LED light(Red/ Green/ Blue)
|
|
|
|
|
|
||||||
|
Tag ID number
|
|
1. A 8-bit hexadecimal number (4 bytes) in the reader. A 10-digit decimal number in software.
2. Can be expanded to 10-bit hexadecimal number (5 bytes). |
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
||||||
Software
The management software is used to setup the patrol schedule at first, then collect, store and process the data collected by patrol readers. It can generate detailed patrol reports, showing employee’s Name, Schedule, Patrol Time, On time or not and other task information. In addition, management software can also be used to monitor patrol activities real time.
