Quick Details
-
Warranty:
-
3 months
-
Brand Name:
-
OLLIN
-
Model Number:
-
OL-50-M
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
670*540*25
-
Poly/Mono:
-
Poly
-
frame:
-
anodized aluminium alloy
-
Color:
-
blue/dark blue
-
junction box:
-
junction box with MC4 connector
-
main market:
-
Asia EU Africa
-
OEM Order:
-
OEM ODM
-
Backsheet:
-
White Back-sheet
-
Application:
-
Solar Power System
-
Front Glass:
-
Glass 3.2mm Tempered
-
Certificate:
-
CE
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell
-
Panel Efficiency:
-
50W
-
Warranty:
-
3 months
-
Brand Name:
-
OLLIN
-
Model Number:
-
OL-50-M
-
Place of Origin:
-
Zhejiang, China
-
Panel Dimensions:
-
670*540*25
-
Poly/Mono:
-
Poly
-
frame:
-
anodized aluminium alloy
-
Color:
-
blue/dark blue
-
junction box:
-
junction box with MC4 connector
-
main market:
-
Asia EU Africa
-
OEM Order:
-
OEM ODM
-
Backsheet:
-
White Back-sheet
-
Application:
-
Solar Power System
-
Front Glass:
-
Glass 3.2mm Tempered
-
Certificate:
-
CE
Product features:
You own the sun. Well, not exactly, but you do have the right to its power. Why not put it good use? With solar technology, you can harness the sun's energy and turn your rooftop into a power plant.
1. With advanced materials and equipment, our modules are designed and manufactured
in consistency with the IEC 61215:1993 standards which can guarantee the excellent electrical
performance and the product life of 25 years.High-transmittance low-iron tempered glass, anti-aging EVA, excellent weathering resistance TPT,
2. High quality anodized aluminum frame is suitable for strong wind resistance and mountain terrain., beautiful appearance
3. Wind resistance, pressure resistance, high conversion efficiency
| Electrical Characteristics | ||||
| STC (Irradiance 1,000W/m2, module temperature 25℃, AM=1.5) | OL50M-10 | |||
| Rated Power (Pmax) | 50W | |||
| Voltage at Pmax (Vmp) |
18.1V |
|||
| Current at Pmax (Imp) |
2.77A |
|||
| Warranted Minimum Pmax | 50W | |||
| Short-Circuit Current (Isc) | 2.99A | |||
| Open-Circuit Voltage (Voc) | 21.6V | |||
| Module Efficiency | 19.00% | |||
| Operating Module Temperature | -40℃ to + 85℃ | |||
| Maximum System Voltage | 1,000V(IEC) / 1,000V(UL) | |||
| Maximum Series Fuse Rating | 15A | |||
| Maximum Reverse Current | 20.25A | |||
| Power Tolerance | 0 ~ +5 W | |||
FAQ
Q: How could I buy the solar panel I need if there is no price in the website?
A: You can send your inquiry to us about the
solar panel
you need, our sales will reply you within 24
hours to help you make the order.
Q: Are you a factory?
A: Yes, sure! We are professional
solar panel
factory with several years of OEM service in ningbo,
China. Welcome you to visit our company when you come to China.
Q: It’s OK to print ourself logo on
solar panel
and package?
A: Sure ! As manufacturer, OEM and ODM are highly welcome.
Q: Could you offer wholesale price?
A: Yes, of course. If you order large quantity, we can give you the bulk price.
Q: How could you ensure the
solar panel
quality excellent?
A: Please do not worry, all items are brand new, and it would be tested one by one before shipment by QC.
If there are some problem for the solar panel after you received it, please feel free to contacts us,
we would give you solution ASAP.
