Quick Details
-
Tube Length(ft):
-
3FT/4FT/5FT/6FT
-
Color Temperature(CCT):
-
3000K/4000K/6000K
-
Product Weight（kg）:
-
5
-
Input Voltage(V):
-
AC110-220V
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-20 - 40
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Yovee
-
Model Number:
-
ALR6535
-
Product Name:
-
Recessed LED Linear Light
-
Material:
-
Aluminum+PC
-
Length:
-
300mm/600mm/900mm/1200mm
-
Power:
-
24/20/18/15/13/10/9
-
Keyword:
-
Modern Linear Light
-
Beam angle:
-
120degree
-
Installation:
-
Recessed
-
Usage:
-
Indoor Housing
-
LED Light Source:
-
SMD2835
-
Type:
-
Led Recessed Linear Light
Quick Details
-
Warranty(Years):
-
3
-
Lamp Luminous Efficiency(lm/w):
-
80
-
Lamp Body Material:
-
Aluminum
-
Tube Length(ft):
-
3FT/4FT/5FT/6FT
-
Color Temperature(CCT):
-
3000K/4000K/6000K
-
Product Weight（kg）:
-
5
-
Input Voltage(V):
-
AC110-220V
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-20 - 40
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Yovee
-
Model Number:
-
ALR6535
-
Product Name:
-
Recessed LED Linear Light
-
Material:
-
Aluminum+PC
-
Length:
-
300mm/600mm/900mm/1200mm
-
Power:
-
24/20/18/15/13/10/9
-
Keyword:
-
Modern Linear Light
-
Beam angle:
-
120degree
-
Installation:
-
Recessed
-
Usage:
-
Indoor Housing
-
LED Light Source:
-
SMD2835
-
Type:
-
Led Recessed Linear Light
Yovee Lighting 20W 40W Recesssed Linear Light Commercial Office Shop 1200mm 4ft Led Linear Light
Specification
FEATURES
- This linear light fixture adopts recessed installation with two optional installation accessories of "N-type buckle" and "butterfly clip" to meet different ceiling structures.
- The main body of this LED light fixture uses high quality AL6063-T5 aluminum and is conducted ultra-precision surface treatment, which can provide 3 optional colors of black, white and silver.
- With professional optical design, the light source plate, PC diffuser and the inner structure of the profile are perfectly matched to produce uniform and soft light.
- The end cap uses magnetic absorption structure, with no need of screw to fix, so the installation and maintenance is extremely convenient.
- There is "small baffle" in the gap between the end cap and diffuser to perfectly solve the problem of light leak. Moreover, after taking down the "small baffle", the diffuser can be disassembled more easily.
- By 180° extender, "L-", "T-", "X-" type light corners and other connecting fittings, this linear light fixtures can be freely combined and applied in arbitrary length and style
BASIC PARAMETERS
| Aluminum material | AL6063-T5 |
| Surface processing | Powder coating , anodizing |
| Cover material | PC |
| Heat dissipation | Max 22W/m |
| Transmittance | >85% |
