Quick Details
-
Certification:
-
ISO9001,ATEX,CE
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Hongyang
-
Model Number:
-
HQJ-01, HQJ-02,
-
Certification:
-
ISO9001,ATEX,CE
|
Specifications : |
||
|
Connection |
Liquid Line |
1",20kgf/cm2,Flange |
|
Gas Line |
1/2",20kgf/cm2,Flange |
|
|
Blow Line |
1/2",20kgf/cm2,Flange |
|
|
Pressure Property |
Max. Operating Pressure |
18kgf/cm2 |
|
Airtightness Test Pressure |
20kgf/cm2 |
|
|
Resisting Test Pressure |
30kgf/cm2 |
|
|
Flow Meter |
Construction |
4-Piston Type |
|
Outlet Diameter |
3/4" |
|
|
MPE |
±0.5% |
|
|
Flow Range |
10~60L/min |
|
|
Tmpperature |
Type |
Electronic |
|
Operating Temp |
-40°C-+50°C |
|
|
Referance Temp |
15°C |
|
|
Display |
Sales Amount |
1~99999999 |
|
Volume |
0.01~99999.99Liter |
|
|
Unit Price |
1~99999.9 |
|
|
Preset |
Provided |
Price.Volume and Accumulated Sales |
|
Self Diagnosis |
Provided |
Self Diagnosis Function,etc |
|
Power Source |
Electrical |
Single Phase,AC220V 50/60Hz |
|
Input Range |
-30%~+30% |
|
|
Safety Coupling |
Separating Pressure |
30kgf/cm2 |
|
Operating Load |
60kgf/cm2 |
|
|
Safety Valve |
Operating Pressure |
13kgf/cm2 |
|
Others |
Anti-Explosion |
Resisting Pressure Anti-Explosion |
|
Excess Flow Valve |
Provided |
|
|
Quick-Coupling |
Provided |
|
|
Strainer |
Provided |
|
|
POS Interface |
RS485 |
|
|
Hose Hook |
Provided |
|
|
Pressure Gauge |
Pressure Range |
0~40kgf/cm2 |
|
Denmension |
Packing Size |
1250*640*1785 |
|
QTY/40'FCL |
38PCS |
|
