Quick Details
-
Weight (KG):
-
550
-
Product name:
-
Centrifugal disk Finishing Machine
-
Usage:
-
de-burring polishing
-
Keyword:
-
Finishing Machine
-
Voltage:
-
customized
-
Machine size:
-
10-120L
-
Polishing work piece material:
-
metal, non-metal
-
Operation:
-
automatic
-
Frequency:
-
50/60
-
Application:
-
polishing
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
KT or OEM
-
Power (kW):
-
6.6
-
Weight (KG):
-
550
-
Product name:
-
Centrifugal disk Finishing Machine
-
Usage:
-
de-burring polishing
-
Keyword:
-
Finishing Machine
-
Voltage:
-
customized
-
Machine size:
-
10-120L
-
Polishing work piece material:
-
metal, non-metal
-
Operation:
-
automatic
-
Frequency:
-
50/60
-
Application:
-
polishing
Centrifugal Disc Finishing Machines are specially suitable for removal of strong burrs, intensive radiusing of small and mid-size parts as well as gently smoothing and high gloss polishing.
Precision Dry/Wet Centrifugal Disc Finishing Machine has fine gap 0.1-0.2mm between disc and barrel for processing thin workpieces.
Feature:
- Compact design suit for both wet and dry processing
- Working barrel is lined inside with hot poured high wear-resistant polyurethane for protracting working life.
- Tough bearing with high wear-resistant ceramic/tungsten ring for dry processing, PU/ceramic ring for wet processing.
- Distinctive gap adjusting system
- Variable frequency inverter Speed control for more option processing.
- Rotary in both clockwise and anti-clockwise.
- Timer for repeatable precision processing.
- Automatic water recycling device
|
Model |
Capacity (L) |
Motor (kW) |
Speed max. (rpm) |
Size (mm) |
Weight (kg) |
|
PVA10 |
10 |
0.37 |
450 |
630x700x1250 |
70 |
|
PVA10/2 |
10x2 |
2x0.37 |
450 |
1030x700x1250 |
130 |
|
PVA10/3 |
10x3 |
3x0.37 |
459 |
1520x700*1250 |
190 |
|
PVA20 |
20 |
0.75 |
450 |
720x800x1450 |
140 |
|
PVA20/2 |
20x2 |
2x0.75 |
450 |
1180x800x1450 |
235 |
|
PVA20/3 |
20x3 |
3x0.75 |
450 |
1700x800x1450 |
330 |
|
PVA38 |
38 |
2.2 |
400 |
900x820x1450 |
220 |
|
PVA38/2 |
38x2 |
2x2.20 |
400 |
1500x820x1450 |
370 |
|
PVA38/3 |
38x3 |
3x2.20 |
400 |
2150x820x1450 |
530 |
]
