Quick Details
-
Reverse Speed(km/h):
-
30
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
NIVO
-
Weight:
-
6000 kg
-
Dimension(L*W*H):
-
6050*2050*3100mm
-
Diesel engine type:
-
YN33GBZ it can be cummins options
-
Rated output:
-
65kw
-
Blade length:
-
3000mm
-
Cylinder Diameter / Stroke:
-
102mm/115mm
-
blade height:
-
480mm
-
blade thickness:
-
18mm
-
Cutter Head Diameter:
-
1090mm
-
Blade Clearance:
-
400mm
-
Cutting Depth:
-
260mm
-
Wheelbase (Front And Rear):
-
4260mm
Quick Details
-
Forward Speed(km/h):
-
40
-
Engine Brand:
-
YUNNEI
-
Working diameter:
-
480mm
-
Reverse Speed(km/h):
-
30
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
NIVO
-
Weight:
-
6000 kg
-
Dimension(L*W*H):
-
6050*2050*3100mm
-
Diesel engine type:
-
YN33GBZ it can be cummins options
-
Rated output:
-
65kw
-
Blade length:
-
3000mm
-
Cylinder Diameter / Stroke:
-
102mm/115mm
-
blade height:
-
480mm
-
blade thickness:
-
18mm
-
Cutter Head Diameter:
-
1090mm
-
Blade Clearance:
-
400mm
-
Cutting Depth:
-
260mm
-
Wheelbase (Front And Rear):
-
4260mm
Product Description
80-350hp motor grader can be optional
Front blade, rear ripper, cabin, A/C, anti-rollover cabin, fender...
|
Engine
|
|
|
Model
|
Yunnei YN33GBZ 65kw 88HP
|
|
Optional
|
Cummins 4BTA3.9-C80 59kw 80HP
|
|
Type(Yunnei engine)
|
Straight Line, Water Cooling, Direct Injection, Four Stroke
|
|
Power Rating
|
65kw
|
|
Engine Displacement
|
3.8L
|
|
Cylinder Diameter / Stroke
|
102mm/115mm
|
|
Minimum Fuel Consumption Rate
|
≤225g/(Kw.h)
|
|
Tractor Parameter
|
|
|
Whole Machine Quality
|
5840Kg
|
|
Maximum Swing Angle Of Front Axle
|
±16°
|
|
Front Wheel Maximum Steering Angle
|
±45°
|
|
Blade Size (Long * High * Thick)
|
3000*480*18mm
|
|
Cutter Head Diameter
|
1090mm
|
|
Hinged Steering Angle Of Frame
|
±23°
|
|
Blade Rotation Angle
|
360°
|
|
Blade Clearance
|
400mm
|
|
Cutting Depth
|
260mm
|
|
Blade Angle
|
Backward 47 Degrees, Forward 5 Degrees
|
|
Blade Slip Range
|
Left 500mm, Right 500mm
|
|
Minimum Ground Clearance Of Front Axle
|
380mm
|
|
Minimum Ground Clearance Of Rear Axle
|
350mm
|
|
Wheel Pitch
|
1590mm
|
|
Wheelbase (Front And Rear)
|
4260mm
|
|
Drive System
|
|
|
The Highest Speed (Forward, Backward)
|
40km/h/、30km/h
|
|
Transmission Type
|
Fixed Axis Power Shift
|
|
Torque Converter Type
|
Single Stage, Single Phase, Three Element
|
|
Gear
|
The First Four, The Last Four
|
|
Tyre
|
16/70-20
|
|
Hydraulic Pressure System
|
|
|
Type
|
Open Type
|
|
System Pressure
|
16Mpa
|
|
Refueling Capacity
|
|
|
Hydraulic Fluid
|
130L
|
|
Diesel Oil
|
100L
|
|
Dimension Length x Width x Height
|
6050×2050×3100mm
|
Front blade and rear ripper can be optional
