Quick Details
-
Brand Name:
-
Optris
-
Theory:
-
Innovative double laser visor
-
Output:
-
0/4~20 mA, 0~5/ 10 V, thermocouple J, K
-
Description:
-
CTlaser-G5L-CF2
-
Temperature range:
-
100 °C ... 1200 °C (212 °F ... 2192 °F) (G5L)
-
Spectral range:
-
5.0 μm
-
Optical resolution (90 % energy):
-
45:1 (G5L, G5HF, G5H1F)
-
Accuracy(ambient temp. 23 ±5 °C):
-
±1 % or ±1.5 °C( ±1 % or ±2.7 °F)
-
Repeatability(ambient tem. 73 ±9 °F):
-
±0.5 % or +0.5 °C( ±0.5 % or +1.8 °F)
-
Temperature resolution (digital):
-
0.1 K
-
Exposure time(90 % signal):
-
120 ms (G5L)
-
Emissivity/ Gain:
-
0.100 ~1.100
-
Signal processing:
-
Peak hold, valley hold, average;extended hold function
-
Software:
-
optris Compact Connect
Quick Details
-
Usage:
-
Precise temperature measurements
-
Model Number:
-
CTlaser-G5L-CF2
-
Place of Origin:
-
Germany
-
Brand Name:
-
Optris
-
Theory:
-
Innovative double laser visor
-
Output:
-
0/4~20 mA, 0~5/ 10 V, thermocouple J, K
-
Description:
-
CTlaser-G5L-CF2
-
Temperature range:
-
100 °C ... 1200 °C (212 °F ... 2192 °F) (G5L)
-
Spectral range:
-
5.0 μm
-
Optical resolution (90 % energy):
-
45:1 (G5L, G5HF, G5H1F)
-
Accuracy(ambient temp. 23 ±5 °C):
-
±1 % or ±1.5 °C( ±1 % or ±2.7 °F)
-
Repeatability(ambient tem. 73 ±9 °F):
-
±0.5 % or +0.5 °C( ±0.5 % or +1.8 °F)
-
Temperature resolution (digital):
-
0.1 K
-
Exposure time(90 % signal):
-
120 ms (G5L)
-
Emissivity/ Gain:
-
0.100 ~1.100
-
Signal processing:
-
Peak hold, valley hold, average;extended hold function
-
Software:
-
optris Compact Connect
Product Description
|
General specifications
|
|
|
|
Environmental rating
|
IP 65 (NEMA-4) front mountable
at vacuum processes (up to 10–3 mbar) |
|
|
Ambient temperature
|
–20 °C ... 85 °C (–4 °F ... 185 °F) (sensing head)
(50 °C [122 °F] with laser ON) –20 °C ... 85 °C (–4 °F ... 185 °F) (electronics) |
|
|
Storage temperature
|
–40 °C ... 125 °C (–4 °F ... 257 °F) (sensing head)
–40 °C ... 85 °C (–40 °F ... 185 °F) (electronics) |
|
|
Relative humidity
|
10 – 95 %, non condensing
|
|
|
Vibration
|
IEC 60068-2-6 (sinus shaped),
IEC 60068-2-64 (broad band noise) |
|
|
Shock
|
IEC 60068-2-27 (25G and 50G)
|
|
|
Weight
|
600 g (21.2 oz) (sensing head)
420 g (14.8 oz) (electronics) |
|
|
Electrical specifications
|
|
|
|
Output / analog
|
0/4 – 20 mA, 0 – 5/ 10 V, thermocouple J, K
|
|
|
Output / alarm
|
24 V / 50 mA (open collector)
|
|
|
Optional
|
Relay: 2 x 60 V DC/ 42 V ACeff; 0.4 A;
optically isolated |
|
|
Output / digital
|
USB, RS232, RS485, Profibus DP, Modbus RTU,
Ethernet (optional) |
|
|
Output impedances
|
mA max. 500 Ω (with 8 – 36 V DC)
mV min. 100 kΩ load impedance thermocouple 20 Ω |
|
|
Inputs
|
Programmable functional inputs for external
emissivity adjustment, ambient temperature compensation, trigger (reset of hold functions) |
|
|
Cable length
|
3 m (standard), 8 m, 15 m
(9.8 ft [standard], 26.2 ft, 49.2 ft) |
|
|
Power supply
|
8 – 36 V DC
|
|
|
Current draw
|
max. 160 mA
|
|
|
Laser 635 nm
|
1 mW, ON/OFF via electronic box or software
|
|
