Quick Details
-
Model Number:
-
UPVC
-
Specification:
-
DN20-800
-
Length:
-
<=11.5m
-
Thickness:
-
2.0-36.8mm
-
Standard:
-
ISO9001
-
Type:
-
Plastic pipe
-
Keyword:
-
Water pipe columns tubes pvc
-
Working pressure:
-
0.63-2.0Mpa
-
Advantage:
-
high pressure
-
Application:
-
waste water, clear water
-
Feature:
-
Heat and wear resistance
-
Shape:
-
Equal
-
OEM:
-
Yes
-
Working Temperature:
-
less than 90℃
-
Connection:
-
socket
Quick Details
-
Processing Service:
-
Cutting
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Olive
-
Model Number:
-
UPVC
-
Specification:
-
DN20-800
-
Length:
-
<=11.5m
-
Thickness:
-
2.0-36.8mm
-
Standard:
-
ISO9001
-
Type:
-
Plastic pipe
-
Keyword:
-
Water pipe columns tubes pvc
-
Working pressure:
-
0.63-2.0Mpa
-
Advantage:
-
high pressure
-
Application:
-
waste water, clear water
-
Feature:
-
Heat and wear resistance
-
Shape:
-
Equal
-
OEM:
-
Yes
-
Working Temperature:
-
less than 90℃
-
Connection:
-
socket
PN16 110mm upvc pvc pipe fitting 4 way 4-way connector cross joint tee
pn16 110mm upvc pvc pipe fitting 4 way 4-way connector cross joint tee as the main raw material, adding a certain amount of additives to the production pipes to form the mixture, and plasticizer is not allowed to be added to the mixture, which ensures the hygienic performance and material stability of PVC-U water supply pipes. The pipes have high liquid pressure resistance, good internal and external wall finish, small fluid resistance, good hygienic performance, and no water quality It is characterized by secondary pollution, light weight, convenient and quick installation, long service life and low comprehensive cost. It can transport drinking water with temperature lower than 45 ℃ and water for other purposes within the specified applicable pressure range of pipes.
Cheap pvc upvc pipe fitting 90 degree elbow,pipe fitting names and parts details
The content of PVC monomer used in the product is not more than 5mg / kg, and the five poisons of additives used can ensure that the hygienic properties of pipes meet the requirements of drinking water. In the process of use, the pipe is free from scaling, algae and other microorganisms, odor, taste and color generated by tap water, and secondary pollution of water quality.
PN16 110mm upvc pvc pipe fitting 4 way 4-way connector cross joint tee reference list
Plastic upvc irrigation pipe, also known as rigid PVC pipe, u-pvc pipe, is a kind of strong corrosion resistance, acid and alkali oil medium corrosion resistance, light weight, certain mechanical strength, good hydraulic conditions, and easy installation.
| UPVC reference list | ||||||
| DN | 0.63Mpa | 0.8Mpa | 1.0Mpa | 1.25Mpa | 1.6Mpa | 2.0Mpa |
| Thickless-mm | ||||||
| 20 | 2.0 | |||||
| 25 | 2.0 | 2.3 | ||||
| 32 | 2.0 | 2.4 | 2.9 | |||
| 40 | 2.0 | 2.4 | 3.0 | 3.7 | ||
| 50 | 2.0 | 2.4 | 3.0 | 3.7 | 4.6 | |
| 63 | 2.0 | 2.5 | 3.0 | 3.8 | 4.7 | 5.8 |
| 75 | 2.3 | 2.9 | 3.6 | 4.5 | 5.6 | 6.9 |
| 90 | 2.8 | 3.5 | 4.3 | 5.4 | 6.7 | 8.2 |
| 110 | 2.7 | 3.4 | 4.2 | 5.3 | 6.6 | 8.1 |
| 125 | 3.1 | 3.9 | 4.8 | 6.0 | 7.4 | 9.2 |
| 140 | 3.5 | 4.3 | 5.4 | 6.7 | 8.3 | 10.3 |
| 160 | 4.0 | 4.9 | 6.2 | 7.7 | 9.5 | 11.8 |
| 180 | 4.4 | 5.5 | 6.9 | 8.6 | 10.7 | 13.3 |
| 200 | 4.9 | 6.2 | 7.7 | 9.6 | 11.9 | 14.7 |
| 225 | 5.5 | 6.9 | 8.6 | 10.8 | 13.4 | 16.6 |
| 250 | 6.2 | 7.7 | 9.6 | 11.9 | 14.8 | 18.4 |
| 280 | 6.9 | 8.6 | 10.7 | 13.4 | 16.6 | 20.6 |
| 315 | 7.7 | 9.7 | 12.1 | 15.0 | 18.7 | 23.2 |
| 355 | 8.7 | 10.9 | 13.6 | 16.9 | 21.1 | 26.1 |
| 400 | 9.8 | 12.3 | 15.3 | 19.1 | 23.7 | 29.4 |
| 450 | 11.0 | 13.8 | 17.2 | 21.5 | 26.7 | 33.1 |
| 500 | 12.3 | 15.3 | 19.1 | 23.9 | 29.7 | 36.8 |
| 560 | 13.7 | 17.2 | 21.4 | 26.7 | ||
| 630 | 15.4 | 19.3 | 24.1 | 30.0 | ||
| 710 | 17.4 | 21.8 | 27.2 | |||
| 800 | 19.6 | 24.5 | 30.6 | |||
PN16 110mm upvc pvc pipe fitting 4 way 4-way connector cross joint tee feature
1.Good mechanical properties
The pipe has good water pressure resistance, external pressure resistance and impact resistance. It has good compression resistance and will not crack when pressed to 1 / 2 of the outer diameter.
2.Corrosion resistance, long service life
It has good corrosion resistance, is not affected by moisture and soil pH, does not conduct electricity, is not sensitive to dielectric corrosion, does not need to do any anti-corrosion treatment when the pipeline is laid, and has a service life of more than 50 years.
3.Low flow resistance
The inner wall is smooth, the flow resistance is small, the roughness is 0.008-0.009, the water delivery capacity is 25% higher than that of cast iron pipe, and 50% higher than that of concrete pipe.
PN16 110mm upvc pvc pipe fitting 4 way 4-way connector cross joint tee application
