Quick Details
-
Brand Name:
-
Allmay
-
Model Number:
-
AM-300XD18YJS
-
Input Voltage(V):
-
185-265
-
Lamp Luminous Flux(lm):
-
900-1200
-
Working Temperature(℃):
-
-20 - 50
-
Name:
-
Lindoor motion sensor ceiling light
-
Material:
-
Iron base+PMMA
-
Function:
-
Microwave sensor & Emergency
-
CCT:
-
2700/6500K
-
Dimension(mm):
-
300*H90
-
LED Type:
-
SMD5730
-
Input Voltage:
-
185-265VAC/50-60HZ
-
Emergency Time:
-
3W/2 hours
-
Rated Power:
-
18W
-
Built In Battery:
-
18650 Lithium Battery
-
Luminous Efficacy(lm/w):
-
70
-
CRI (Ra>):
-
70
-
Working Lifetime(Hour):
-
30000
Quick Details
-
Lamp Body Material:
-
Iron
-
Design Style:
-
Contemporary
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Allmay
-
Model Number:
-
AM-300XD18YJS
-
Input Voltage(V):
-
185-265
-
Lamp Luminous Flux(lm):
-
900-1200
-
Working Temperature(℃):
-
-20 - 50
-
Name:
-
Lindoor motion sensor ceiling light
-
Material:
-
Iron base+PMMA
-
Function:
-
Microwave sensor & Emergency
-
CCT:
-
2700/6500K
-
Dimension(mm):
-
300*H90
-
LED Type:
-
SMD5730
-
Input Voltage:
-
185-265VAC/50-60HZ
-
Emergency Time:
-
3W/2 hours
-
Rated Power:
-
18W
-
Built In Battery:
-
18650 Lithium Battery
-
Luminous Efficacy(lm/w):
-
70
-
CRI (Ra>):
-
70
-
Working Lifetime(Hour):
-
30000
12W 15W 18W Indoor Rechargeable emergency led motion sensor ceiling light for corridor hallway Flat Hotel
- When Power is switched ON, The luminaire will turn ON with motion activated, turn off (or dim light) if no motion, The internal battery will begin to charge.
- Note: the internal battery will take 24 hours to fully charge.
- When power is cut, the luminaire automatically switches into emergency mode, running at 10-15% output using the internal battery. (for 100mins when fully charged)
- Once power is restored, the luminaire will be running at full output each time when the microwave sensor is activated. The battery will begin to re-charge.
12W 15W 18W microwave induction rechargeable emergency led motion sensor ceiling light for corridor
Specifications of emergency 15/18W led radar sensor ceiling light :
| Type | Motion sensor led ceiling light with build-in battery | |
| Model | AM-XD-300RDYJ15 | AM-XD-300RDYJ18 |
| Full Power | 15W | 18W |
| LED Qty | 30pcs*SMD5730 | 36pcs*SMD5730 |
| Rated Lumen | 800-900lumen | 800-900lumen |
| CRI | >70 | >70 |
| CCT | 2700K/6000K | 2700K/6000K |
| Power Factor | >0.9 | >0.9 |
| Beam Angle | 120 degree | 120 degree |
| Product Sizes (mm) | Φ300*H90 | Φ300*H90 |
| Color box Sizes(mm) | 370*370*110 | 370*370*110 |
| Structure | Steel base & Acrylic cover | Steel base & Acrylic cover |
| Sensor data | ||
| Sensor distance | 6-8m radius | 6-8m radius |
| Delay time | 15+/-5s | 15+/-5s |
| Sensor Principle | HF Microwave 5.8GHz | HF Microwave 5.8GHz |
| Transmission power | <0.2mW | <0.2mW |
| Detection range: Max(diameter*H) | 8m*6m | 8m*6m |
| Detection angle | 30° ~150° | 30° ~150° |
| Sensor Mode |
On/Off Full/Dim (100%~20%) |
On/Off Full/Dim (100%~20%) |
| Emergency Data | ||
| Emergency Power | 3W | 3W |
| Lithium Battery | 18650, 12V, 1200mAh | 18650, 12V, 1200mAh |
| Backup time | 90-110 mins | 90-110 mins |
| Operation Temperature(Ta) | -10~40°c | -10~40°c |
| IP Rating | IP20 | IP20 |
| Function |
1. Connect to main power, (AC100-265V), The light work as a sensor light. (Full/dim mode)
2. When power failure/Outage, The light work on emergency Backup mode, Backup power: 3W, Backup time: 90-110mins |
|
Customer Questions & Answers
- Sensor type A : ON/OFF Mode (100%-0%)
when detect movement lighting, Light turn on at 100% brightness,
no movement, stand by status light off (0%)
- Sensor type B : Sensor Full/Dim Mode (100%~20%)
when detect movement lighting, Light turn on at 100% Brightness,
no movement, stand by status lighting turn to 20% (2-3 watt)
- Delay time: 20 seconds
( mean, the last movement past, light still keep on lighting 20 seconds)
- Brightness(Daylight) Sensor <10 lux (Optional)
with brightness sensor, that mean motion sensor only work at night,
even if there is movement in daytime,the light doesn't light on.
- Quality control:
we have three sensor test rooms, make sure each lamps passed stricly sensor function test and aging test before shipping.
- Warranty : 2 years
- Application: corridor stair way warehouse, hallyway, Closet, Depot, Bathroom, Toilet, Childern Room.etc.
Product application:
