Quick Details
-
Controller Type:
-
MPPT, PWM
-
Mounting Type:
-
Roof Mounting
-
Certificate:
-
CE
-
Warranty:
-
Contact us.
-
Place of Origin:
-
China
-
Model Number:
-
JH-OF-A5.5KW
-
Load Power (W):
-
5.5KW
-
Output Voltage (V):
-
220V/110V, EU: 220-240/380-400V US: 110/120/208/240/277/480V
-
Output Frequency:
-
50HZ/60HZ
-
Work Time (h):
-
24
-
Product name:
-
Solar Power System
-
Type:
-
Off Grid System
-
Solar panel:
-
Mono
-
Inverter:
-
Off Grid Inverter
-
Inverter Type:
-
Single Phase Inverter
-
Controller:
-
MPPT Controller (Optional)
-
Mounting Structure:
-
Roof Ground Mounting Bracket
-
Cable:
-
4 mm²
Quick Details
-
Application:
-
Home
-
Solar Panel Type:
-
Monocrystalline Silicon, Polycrystalline Silicon
-
Battery Type:
-
Lead-Acid, Lithium Ion
-
Controller Type:
-
MPPT, PWM
-
Mounting Type:
-
Roof Mounting
-
Certificate:
-
CE
-
Warranty:
-
Contact us.
-
Place of Origin:
-
China
-
Model Number:
-
JH-OF-A5.5KW
-
Load Power (W):
-
5.5KW
-
Output Voltage (V):
-
220V/110V, EU: 220-240/380-400V US: 110/120/208/240/277/480V
-
Output Frequency:
-
50HZ/60HZ
-
Work Time (h):
-
24
-
Product name:
-
Solar Power System
-
Type:
-
Off Grid System
-
Solar panel:
-
Mono
-
Inverter:
-
Off Grid Inverter
-
Inverter Type:
-
Single Phase Inverter
-
Controller:
-
MPPT Controller (Optional)
-
Mounting Structure:
-
Roof Ground Mounting Bracket
-
Cable:
-
4 mm²
Product Advantages
Advantages of Solar Energy System
1. Renewable Energy Source
It can be harnessed in all areas of the world and is available every day. We cannot run out of solar energy, unlike some of the other sources of energy.
2. Reduces Electricity Bills
How much you save on your bill will be dependent on the size of the solar system and your electricity or heat usage.
3. Diverse Applications
Solar energy can be used for diverse purposes. You can generate electricity (photovoltaic) or heat (solar thermal). Solar energy system can be used to produce electricity in areas without access to the energy grid.
4. Low Maintenance Costs
Solar energy systems generally don’t require a lot of maintenance. You only need to keep them relatively clean, so cleaning them a couple of times per year will do the job.
Our main products include solar system from 3 KW to 60 KW, solar batteries, inverters and solar panels.
Some products can be customized brand, logo, color, shape with MOQ restrictions.
|
JHORSE OFF GRID SOLAR SYSTEM SOLUTIONS
|
|
|
|
|
|
|||||
|
Model
|
JHorse 3.5KW
|
JHorse 5.5KW
|
JHorse 10KW
|
JHorse 15KW
|
JHorse 20KW
|
|||||
|
550W Solar Panel
|
4
|
8
|
18
|
28
|
36
|
|||||
|
Solar Inverter
|
3500W
|
5000W
|
10KW
|
15KW
|
20KW
|
|||||
|
Battery
|
12V 150AH
6PCS
|
12V 150AH
8PCS
|
12V 150AH
8PCS
|
12V 200AH
16PCS
|
12V 200AH
16PCS |
|||||
|
PV Combiner
|
4 in, 1 out
|
4 in, 1 out
|
4 in, 1 out
|
4 in, 1 out
|
4 in, 1 out
|
|||||
|
Panel Rack
|
1 SET
|
2 SET
|
5 SET
|
7 SET
|
9 SET
|
|||||
|
Cable
|
100 M
|
100 M
|
600 M
|
600 M
|
600 M
|
|||||
|
OFF GRID 5.5KW SOLAR SYSTEM
|
|
|
|
|||
|
Item
|
Module
|
Specification
|
Quantity
|
|||
|
1
|
Solar Panel
|
Max. Power: 550W
Voltage: 50.1V
Max. Working Current: 13A
Size: 2256*1133*35 mm
Net Weight: 28.5/pcs
|
8 pcs
|
|||
|
2
|
Solar Battery
|
Lead Acid Battery
12V 150AH
|
8 pcs
|
|||
|
3
|
Off Grid Inveter
|
Rate Power: 5500W
DC Input Voltage: 48V
AC Output Voltage: 220V/110V
Solar Controller: MPPT 100A
Phase: Single
Max. PV Power: 4500W
|
1 pcs
|
|||
|
4
|
Panel Rack
|
Ground/cement flat roof
Roof Slope: Max. 60°
Wind Load: Max. 130mph (60m/s)
Snow Load: Max 30psf (1.4kN/㎡）
|
2 set
|
|||
|
5
|
PV Cable
|
4mm² (black+red)
|
100 m
|
|||
|
6
|
PV Combiner
|
4/1 1000V
|
1 pcs
|
|||
