- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
CL-1004
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
HGG
-
Rated voltage:
-
AC110/240V/DC12/24/48/36V
-
Operating lllumination:
-
Turn-ON Less 30Lus ---Turn-off Less 150Lus
-
Off delay time:
-
0.1S
-
Power Consumer:
-
Max 2.0W
-
Color:
-
Blue+white
-
Material:
-
electrical components
-
Brand:
-
HGG
-
MODEL:
-
CL1004
-
Current Rating:
-
10A
-
package qty:
-
100pcs/carton box
Quick Details
-
Usage:
-
day and night photocontrol switch
-
Mounting Type:
-
none
-
Description:
-
none, photocell controller.
-
Model Number:
-
CL-1004
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
HGG
-
Rated voltage:
-
AC110/240V/DC12/24/48/36V
-
Operating lllumination:
-
Turn-ON Less 30Lus ---Turn-off Less 150Lus
-
Off delay time:
-
0.1S
-
Power Consumer:
-
Max 2.0W
-
Color:
-
Blue+white
-
Material:
-
electrical components
-
Brand:
-
HGG
-
MODEL:
-
CL1004
-
Current Rating:
-
10A
-
package qty:
-
100pcs/carton box
We manufacture all kinds of led street light/led flood light/led high bay light ,
led driver, as well as all kinds of traditional street light/floodlight and accessories like ballast, ignitor, capacitor , bulb and photocell etc.
Photocell Dusk to Dawn Button Photo Control Eye Photoelectric Switch Flush Mount
photoelectric switch street light
Lux Sensor (Photocell sensor)
Automatic Auto On Off Photocell Street Light Switch DC AC 220V 50-60Hz 10A Photo Control Photoswitch Sensor Electrical Switch
outdoor photocell switch 220v
Automatic Auto On Off Photocell street Light Switch DC AC 220V 50-60Hz 10A Photo Control Photoswitch Sensor Switch
Automatic (Control electrical) Auto On Off Street Light Switch Photo Control Sensor (61ry242qf440) AC 220V
AC 220V 10A Automatic Auto On Off Photocell Street Light Switch 50-60Hz 10A Photo Control Photoswitch Sensor
Ac Dc 12v 10a Auto on Off Photocell Light Switch Photoswitch Light Sensor Switch
AC 220V 10A Automatic Auto On Off Photocell Street Light Switch 50-60Hz 10A Photo Control Photoswitch Sensor
12vdc daylight switch
photoelectric light control
Automatic Auto On Off Photocell street Light Switch DC AC 220V 50-60Hz 10A Photo Control Photoswitch Sensor Switch
Automatic Auto On Off Photocell street Light Switch DC AC 220V 50-60Hz 10A Photo Control Photoswitch Sensor Switch
Automatic Auto On Off Photocell street Light Switch DC AC 220V 50-60Hz 10A Photo Control Photoswitch Sensor Switch
Automatic Auto On Off Photocell street Light Switch DC AC 220V 50-60Hz 10A Photo Control Photoswitch Sensor Switch
Automatic Auto On Off Photocell street Light Switch DC AC 220V 50-60Hz 10A Photo Control Photoswitch Sensor Switch
A perfect replacement wall pack photocell, postlamp button dusk-to-dawn, flood light photocell or pole light photo sensor in applications where you are using HID, Induction, LED or CFL outdoor lighting systems
When you are testing the photocell, be sure to turn on the power (load will come on) and wait up to 5 minutes for the photocell to switch load off. For further testing cover the photo control completely with black tape or another dark material to simulate night conditions. If you cant cover the control with tape, try covering the photo control with the shipping carton to simulate night conditions.
Do not face the photocell into the midday sun. If the photo control is installed on the south side of a building, face the photocell east or west or point the photo control down toward the ground. The best direction to face the photo control is north.
Do not face the photocell where it can see artificial light. Light from windows, signs, street lights, etc., will cause the photo control not to switch on. The photo control should not be positioned so that it sees the light it is controlling (or reflected light - like off of your white siding or white painted soffit overhang). These conditions will cause the light to cycle on and off.
Do not install the photo control with wires up unless there is NO POSSIBILITY of water entering the photo control around the wires.
The photo control must be installed in an approved weatherproof box. Do not attempt to caulk around the wires. Installing a Photocell below the box is WRONG! Photocells installed on top of the Box is RIGHT!
Photocell Dusk to Dawn Button Photo Control Eye Photoelectric Switch Flush Mount
PHOTOCONTROL,
| Color ( Mix color we accept ) | We accept Mix color in batch , any color accept only your provide pantone No.to us or we have pantone No. for you selection |
| MOQ ( small Qty accept ) |
10-50-100-200-500-1000-5000-10000-20000 pcs depends on different watts, model and process. MIN and SMALL quantity accept |
| Price ( Factory Lowest price ) | We are factory (our factory add for you check: No.2025 Luoning Road, Baoshan District,Shnaghai China. New factory address: No.393 Zhongxing Road, Changzhou,Jiangsu, China . |
| Production time |
Sample: Natural packing and stock goods only within 1 day send out sample for you.
Other customized sample time:2-5days,
Mass good time: 7-15 days ,biggest order depends on quantity |
| Package details |
We have general packing, white/brown, color box diffrent ways package . Eg: Each one put in Bubble paper bay avoid scratch. Each one with inner box and carton. |
| Warm tips |
More products details, our Advantage, packge ways, lowest price etc pls check nex details and contact us (E: Alex at lipulighting.com, Tel:0519-8268-8578 Phone:86 18052535912(Wechat/Whatsapp), it is our honor to service for you always |
AC DC 12V 10A Auto On Off Photocell Light Switch Photoswitch Light Sensor Switch(Pack of 2)
AC DC 12V 10A Auto On Off Photocell Light Switch Photoswitch Light Sensor Switch(Pack of 2)
