Quick Details
-
Fork Length:
-
1070mm
-
Fork Width:
-
250-1060mm
-
Overall Dimensions:
-
2180*800*1400 mm
-
Weight (KG):
-
4995 kg
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
HELI
-
Fork Length:
-
1070mm
-
Fork Width:
-
250-1060mm
-
Overall Dimensions:
-
2180*800*1400 mm
-
Weight (KG):
-
4995 kg
|
Model
|
|
CPD30
|
|
Load capacity
|
kg
|
1000
|
|
Load centre
|
mm
|
500
|
|
Height drawbar in driving position min./max.
|
mm
|
3000
|
|
Height, when the frame retracts
|
mm
|
2070
|
|
Height of mast, extended
|
mm
|
4217
|
|
Overall length
|
mm
|
3637
|
|
Overall width
|
mm
|
1260
|
|
Fork dimensions
|
mm
|
45/125/1070
|
|
Aisle width for pallets 1000 x 1200 crossways
|
mm
|
3912
|
|
Aisle width for pallets 800 x 1200 lengthways
|
mm
|
4115
|
|
Turning radius
|
mm
|
2235
|
|
Max. gradeability, laden/unladen
|
%
|
17/26
|
|
Travel speed (full load/no load)
|
km/h
|
14.5/15
|
|
Lifting speed (full load/no load)
|
m/s
|
0.320/0.44
|
|
Lowering speed, with/without load
|
m/s
|
0.123/0.107
|
|
Self-weight (with battery)
|
kg
|
4995
|
Operating table
Easy to use the console, easy to control the car lift.
Integrated water cup trough
Integrated water cup trough, large car handle, more intimate details design
console
Proprietary development of the right control valve stem, more in line with driving habits door frame vision, more comfortable operation steering wheel can be adjusted front and rear, flexible to adapt to different drivers sufficient cockpit space, more comfortable driving USB charging port, emergency charging more convenient.
