Quick Details
-
Weight:
-
355 KG
-
Dimension(L*W*H):
-
2700*1200*1050mm
-
Model:
-
RT90
-
Structure Weight:
-
240kg
-
Tilling Width:
-
900mm
-
Tilling Depth:
-
150mm
-
PTO Turning Speed:
-
540r/min
-
Tractor HP:
-
15-20hp
Quick Details
-
Use:
-
free soil
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Rima
-
Weight:
-
355 KG
-
Dimension(L*W*H):
-
2700*1200*1050mm
-
Model:
-
RT90
-
Structure Weight:
-
240kg
-
Tilling Width:
-
900mm
-
Tilling Depth:
-
150mm
-
PTO Turning Speed:
-
540r/min
-
Tractor HP:
-
15-20hp
1. Transmission: chain driven.
2. Gearbox is made of graphite casting iron . Material performance is better. Not easy broken.
3. The suspension plate shape is not easy to deform.
4. Chain device hand adjustable. More easy and reliable.
5. Side protection plates are added onto the rear deflection. This device prevents the soil flying out.
6. The tilling height can be adjustable.
7. The structure is firm and stable
1. 3 point linkage
2. Graphite casting iron gearbox
3. Tractor power required: 15-35hp / 20-45hp
|
Model |
S PA 125 |
S PA 145 |
S PA 165 |
|
Size (L*W * H) |
1360x1330x920mm |
1560x1330x920mm |
1760x1330x920mm |
|
Net weight |
355kg |
380kg |
405kg |
|
Working width |
1150mm |
1350mm |
1550mm |
|
Working depth |
120mm |
120mm |
120mm |
|
Work efficiency |
1800-2400m2 /h |
2100-2800m2 /h |
2400-3200m2 /h |
|
PTO speed |
540r/min |
540r/min |
540r/min |
|
PTO spline |
6x8x700mm |
6x8x700mm |
6x8x700mm |
|
Supporting force |
25-30hp |
28-40hp |
35-45hp |
|
|
Include PTO shaft |
||
