Model
|
DS-1260SJ
|
|
|
|
|||
|
Print heads
|
Eps XP600 Printhead(DX5 DX7 i3200 for option)
|
37.5KW
|
|
|
|||
|
Number of heads
|
2 pieces printheads
|
2.8 M3
|
|
|
|||
|
Ink Type
|
Eco Solvent Ink / Sublimation Ink / Water based Ink / UV Curing ink
|
125Ton
|
|
|
|||
|
Printing Width
|
3.25m(127.9in)
|
96kN
|
|
|
|||
|
Printing Speed
|
4 Pass
|
45 m²/Hour
|
|
|
|||
|
|
6 Pass
|
30 m²/Hour
|
|
|
|||
|
|
8 Pass
|
22 m²/Hour
|
|
|
|||
|
Maximum Resolution
|
1440dpi Max.
|
|
|
|
|||
|
Print Height
|
1mm to 5mm adjustable
|
|
|
|
|||
|
Ink Colors
|
2*CMYK
|
|
|
|
|||
|
Printing Materials
|
Vinyl, Flex banner, One way vision, reflective sticker, mesh etc
|
|
|
|
|||
|
Data Interface
|
USB2.0 High Speed Interface Transfer System
|
|
|
|
|||
|
|
Temperature
|
15℃-30℃
|
|
|
|||
|
|
Humidity
|
40%-60%
|
|
|
|||
|
|
50-60HZ 400W-1600W
|
|
|
|
|||
|
|
AC220V±10% / AC110V±10%
|
|
|
|
|||
|
Operating System
|
Windows XP, Windows 7, Windows 10
|
|
|
|
|||
|
Packing Dimension
|
5.0*1.2*1.6m(Assembled packing)
|
|
|
|
|||
|
Gross Weight
|
450KG
|
|
|
|
|||
|
|
2 Liters Big Capacity CISS system
|
|
|
|
|||
|
|
Auto Feeding & Take-up Media System
|
|
|
|
|||
|
|
Infrared Heating system & Front Dry Fans
|
|
|
|
|||
|
|
LED Strip light for Carriage Position
|
|
|
|
|||
