Quick Details
-
Brand Name:
-
original
-
Model Number:
-
WS-C2960-48TT-L
-
Place of Origin:
-
United States
-
Product Name:
-
WS-C2960-48TT-L
-
Device Type:
-
2960 48 Port switch
-
Certification:
-
Other
Quick Details
-
Transmission Rate:
-
10/100Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
32Gbps
-
Brand Name:
-
original
-
Model Number:
-
WS-C2960-48TT-L
-
Place of Origin:
-
United States
-
Product Name:
-
WS-C2960-48TT-L
-
Device Type:
-
2960 48 Port switch
-
Certification:
-
Other
24 or 48 Fast Ethernet ports
Small Form-Factor Pluggable (SFP) and 1000BASE-T Gigabit Ethernet uplinks
IEEE 802.3af-compliant Power over Ethernet (PoE)
LAN Base or LAN Lite IOS ® Software feature set
SmartOperations tools that simplify deployment and reduce the cost of network administration
EnergyWise technology to manage energy consumed by connected devices
An enhanced limited lifetime hardware warranty (E-LLW), providing next-business-day replacement
Applications and Benefits
Branch offices, remote sites, and retail locations
Conventional desktop workspaces
Building infrastructure, physical security, and other nontraditional access applications
Robust quality of service (QoS) that prioritizes voice and critical business applications
Flexible security features that can limit access to the network and mitigate threats
Tools that reduce total cost of ownership through simplified operations and automation
| WS-C2960-48TT-L Product Details | |
|---|---|
| Device Type | Switch - 48 ports - Managed |
| Enclosure Type | Rack-mountable - 1U |
| Ports | 48 x 10/100 + 2 x 10/100/1000 |
| Performance | Switching capacity : 32 Gbps ¦ Forwarding performance (64-byte packet size) : 10.1 Mpps |
| MAC Address Table Size | 8K entries |
| Remote Management Protocol | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH |
| Features | Layer 2 switching, auto-sensing per device, dynamic IP address assignment , auto-negotiation, BOOTP support, ARP support, load balancing, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, DiffServ support, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), Link Aggregation Control Protocol (LACP), Port Security, MAC Address Notification, Remote Switch Port Analyzer (RSPAN) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP) |
| Power | AC 120/230 V ( 50/60 Hz ) |
| Dimensions (WxDxH) | 44.5 cm x 33.1 cm x 4.4 cm |
| Weight | 3.63 kg |
