Quick Details
-
Design Printing:
-
No printing
-
Material:
-
PVC
-
Feature:
-
Heat-Resistant
-
Use:
-
Carton Sealing
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
3M
-
Model Number:
-
9472le
-
Color:
-
Clear
-
Product name:
-
High Performance Adhesive Transfer Tapes
-
Application:
-
Carton Package
-
Name:
-
High Performance Adhesive Transfer Tapes
-
Width:
-
48mm
-
Thickness:
-
0.13mm
-
Usage:
-
Packing Cartons
-
Length:
-
55m
-
Certificates:
-
SGS/SDS/ISO 9001
-
Type:
-
General Used
Quick Details
-
Adhesive:
-
Acrylic
-
Adhesive Side:
-
Double Sided
-
Adhesive Type:
-
Pressure Sensitive
-
Design Printing:
-
No printing
-
Material:
-
PVC
-
Feature:
-
Heat-Resistant
-
Use:
-
Carton Sealing
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
3M
-
Model Number:
-
9472le
-
Color:
-
Clear
-
Product name:
-
High Performance Adhesive Transfer Tapes
-
Application:
-
Carton Package
-
Name:
-
High Performance Adhesive Transfer Tapes
-
Width:
-
48mm
-
Thickness:
-
0.13mm
-
Usage:
-
Packing Cartons
-
Length:
-
55m
-
Certificates:
-
SGS/SDS/ISO 9001
-
Type:
-
General Used
Product Description
3M™ Adhesive Transfer Tape 9472LE
Specifications
|
Attribute Name
|
Value
|
|---|---|
|
Adhesive Type
|
3M™ Acrylic Adhesive 300LSE
|
|
Applications
|
Gasket Assembly, Large Surface Lamination Assembly, Mounting and Trim Attachment
|
|
Brand
|
3M, 3M™
|
|
Color
|
Clear
|
|
Face-Side Adhesive Thickness
|
5.2 mil
|
|
Face-Side Adhesive Thickness (metric)
|
0.13 mm
|
|
Face-Side Adhesive Type
|
3M™ Low Surface Energy Acrylic Adhesive 300LSE
|
|
Indoor/Outdoor
|
Both
|
|
Industries
|
Appliance, Automotive, Construction, Converter Solutions, Electronics, General Industrial, Medical, Metalworking, Military, Military & Government, MRO, Oil and Gas, Paper, Signage, Specialty Vehicle, Transportation, Woodworking
|
|
Length
|
10 Linear Yard, 100 Linear Yard, 180 Linear Yard, 250 Linear Yard, 3 Linear Yard, 360 Linear Yard, 60 Linear Yard, 60.15 Linear Yard
|
|
Length (Metric)
|
164.59 m, 165 m, 2.74 m, 228 m, 329.18 m, 54.86 m, 54.99 m, 55 m, 9.14 m, 91.44 m
|
|
Master Size Length
|
180 Linear Yard
|
|
Master Size Width
|
54 Inch
|
|
Maximum Operating Temperature (Celsius)
|
149 Degree Celsius
|
|
Maximum Operating Temperature (Fahrenheit)
|
300 Degree Fahrenheit
|
|
Minimum Operating Temperature (Fahrenheit)
|
-40 Degree Fahrenheit
|
|
Position
|
Best
|
|
Primary Liner
|
58# Polycoated Kraft Paper (PCK)
|
|
Primary Liner Color
|
Tan
|
|
Primary Liner Thickness
|
4.2, 4.2 mil
|
|
Product Form
|
Each, Roll
|
|
Shear Strength at 72 Degrees F (22 Degrees C)
|
Medium
|
|
Size
|
Custom
|
|
Specifications
|
Ford, GM, Nissan
|
|
Substrates
|
EPDM Rubber, Glass, HSE Plastics and Glass, LSE Plastics, Metal, Oily, Paint, Paints (Powder Coat, Painted Metal, Composite Panel), PTFE, Rubber (Except EPDM), Smooth
|
|
Tape Thickness
|
5 Milli-inch (mil), 5.2 Milli-inch (mil)
|
|
Thickness
|
5.2 mil
|
|
Thickness (Metric)
|
0.13 mm, 0.132 mm
|
Details
- Excellent bond to low surface energy substrates including powder coatings and plastics such as polypropylene (PP)v
- High adhesion to metals and high surface energy materials, making it suitable for bonding dissimilar substrates
- Adhesive provides excellent holding power and anti-lifting properties
- Good resistance to industrial chemicals, consumer chemicals, moisture and humidity
- Ideal solution for general purpose attachment and assemblies of a wide variety of materials
- Meets a wide variety of automotive and OEM specifications
Our 3M™ Adhesive Transfer Tape 9472LE is a versatile, market proven, 5 mil (0.13 mm) transfer tape on a printed release liner. Featuring 3M™ 300LSE acrylic adhesive, this tape has a long and proven history of reliably bonding a wide variety of similar and dissimilar materials such as metals, most plastics, glass, papers and painted surfaces.
Versatile, Market Leading Performance
For applications requiring premium performance and a thicker profile than our 2 mil tapes, use our versatile 3M™ Adhesive Transfer Tape 9472LE. This tape is a market leading solution for bonding plastics in a variety of applications across a broad spectrum of industries. It offers good chemical, humidity and moisture resistance, as well as performance across a wide temperature range (from -40°F/-40°C to 300°F/148°C). The bond strength increases as a function of time and temperature, and has very high initial adhesion. This tape is supplied on a printed 58 lb. polycoated kraft paper liner ideal for die-cutting and converting applications. Part of the 3M™ High Strength Acrylic Adhesive 300LSE family, this tape is manufactured using a solventless manufacturing process. 3M™ Adhesive Transfer Tape 9472LE meets UL 969 (reference file PGGU2.MH26206).
For applications requiring premium performance and a thicker profile than our 2 mil tapes, use our versatile 3M™ Adhesive Transfer Tape 9472LE. This tape is a market leading solution for bonding plastics in a variety of applications across a broad spectrum of industries. It offers good chemical, humidity and moisture resistance, as well as performance across a wide temperature range (from -40°F/-40°C to 300°F/148°C). The bond strength increases as a function of time and temperature, and has very high initial adhesion. This tape is supplied on a printed 58 lb. polycoated kraft paper liner ideal for die-cutting and converting applications. Part of the 3M™ High Strength Acrylic Adhesive 300LSE family, this tape is manufactured using a solventless manufacturing process. 3M™ Adhesive Transfer Tape 9472LE meets UL 969 (reference file PGGU2.MH26206).
Recommended Applications
3M™ High Strength Acrylic Adhesive 300LSE is an acrylic adhesive family designed to provide very high bond strength to most surfaces, including a wide variety of similar and dissimilar materials. This includes most plastics, metals, glass, papers and painted surfaces. It features good chemical, solvent, moisture and humidity resistance. This adhesive can perform at temperatures ranging up to 300°F/148°C.
- Bonding rough substrates such as textured plastics
- Plastic to metal bonding
- Consumer electronic device assemblies such as phones, tablets and wearable devices
- Industrial electronic device assemblies such as workstations
- Plastic assembly bonding in a variety of industries
- Various assemblies in the automotive industry
- Application and assembly of components on appliances
- Medical equipment and device fabrication
- General industrial applications such as trim attachment
3M™ High Strength Acrylic Adhesive 300LSE is an acrylic adhesive family designed to provide very high bond strength to most surfaces, including a wide variety of similar and dissimilar materials. This includes most plastics, metals, glass, papers and painted surfaces. It features good chemical, solvent, moisture and humidity resistance. This adhesive can perform at temperatures ranging up to 300°F/148°C.
| Adhesive Family | Features |
| 350 |
• Best in class for high temperature resistance 350°F (177°C) and shear strength
• Excellent solvent resistance for harsh environments • Best for challenging applications |
| 360 |
• More strength with less adhesive
• Quick stick properties to many LSE substrates • Lowest ooze • Low odor • Excellent convertability (die-cut) |
| 300LSE |
• Best in class for oily substrates
• Thicker "Go To" tapes for LSE substrates • Good chemical and humidity resistance |
| 300MP |
• Multi-purpose use for many applications
• Bonds very well to foam, fabrics and many plastics • Economical attachments of graphics |
Note: This technical information and data should be considered representative or typical only and should not be used for specification purposes.
What are Adhesive Transfer Tapes?
Adhesive transfer tapes are double sided tapes comprised of a uniform layer of pressure sensitive adhesive pre-applied to a special release liner. For application, the tape is simply pressed, adhesive face side down, to a surface and the liner is peeled off to expose the backside of the adhesive for attachment. These adhesives and liners are available in a variety of thicknesses to meet a broad selection of applications in numerous industries.
Learn more about 3M Industrial Adhesives and Tapes (PDF, 45 Mb)
Our Services
We can offer professional die cutting service according to customer’s request or drawing (any shape and any size) with above cutting machines. If any question, please do not hesitate to contact with us.
